Exclusively providing a Thunderbolt™/NAS/iSCSI SAN triple solution, the TVS-1582TU offers four high-bandwidth Thunderbolt™ 3 ports for optimizing 4K video transfer and online editing. It is a perfect match for Thunderbolt-equipped Mac® and Windows® users for 4K workflows, file storage and high-speed sharing. The compact rack-mounted form factor makes the TVS-1582TU especially useful for SNG/OB van live media production that requires frequent relocation. The TVS-1582TU adopts 7th Generation Intel® 14nm multi-core processors and was designed around the concept of tiered storage, application-based partitioning and network traffic distribution to fulfill critical tasks with sophisticated capabilities.

  • A hybrid NAS supporting 3.5” & 2.5” drives in one chassis
  • Qtier technology and SSD cache enable 24/7 optimized storage efficiency
  • The Network & Virtual Switch app assists network traffic distribution and re-routes dedicated bandwidth for diverse applications
  • Superior 4K video playback and transcoding
  • Four Thunderbolt™ 3 (40 Gbps) ports and dual 10GbE ports for on-the-fly video editing and rapid file sharing
  • Four available combinations with Mac/PC and JBOD for flexible attaching, sharing and expansion
  • Flexible storage expansion with QNAP storage expansion enclosures and Virtual JBOD (VJBOD)
  • Supports QRM+ unified remote server management, virtualization (storage and hosting), containerization, and WirelessAP service

Note:
1. Requires MacOS Sierra 10.12.3 (or later) for using Thunderbolt connection on Mac.
2. Thunderbolt 3 reaches the maximum theoretical transfer rate of 40 Gigabits per second. Actual performance may vary due to hardware/software limitations and usage environment.
3. Thunderbolt 3 (40 Gbps) doubles its theoretical potential for speed when compared to Thunderbolt 2 (20 Gbps). This results in the TVS-1582TU’s file transfer speed increasing from 900 MB/s to 1,600 MB/s.

Thunderbolt™ 3 NAS, extraordinary performance

Featuring high-performance 7th Generation Intel® processors, the TVS-1582TU provides two options powered by an Intel® Core™ i5 quad-core processor with 16GB DDR4 RAM and Intel® Core™ i7 quad-core processor with 32GB DDR4 RAM (both upgradable to 64GB RAM), driving outstanding system performance for CPU-demanding applications. The TVS-1582TU Thunderbolt™ 3 NAS not only features Thunderbolt™ 3 technology for faster data transfer but also has dual 10GbE ports giving you incredible flexibility for network connectivity. The Thunderbolt™ 3 ports on the TVS-1582TU are also compatible with USB Type-C cables/devices and supports 10 Gbps USB 3.1 Gen2, allowing compatibility with newer, faster USB external drives/enclosures for transferring large-sized media files.

Note: Thunderbolt cables are sold separately. Thunderbolt 3 (USB-C) to Thunderbolt 2 converters may not be compatible with certain Windows PC models.

Learn more: QNAP Thunderbolt™ 3 Solution

Thunderbolt™ 3 certified cable

Next-generation Thunderbolt™ 3 delivers bi-directional 20 Gbps speeds. Use a certified Thunderbolt™ 3 40 Gbps cable (with the Thunderbolt icon and “3”) and an SLC/MLCSSD RAID5 configuration to enjoy the highest possible performance and the best storage allocation for your NAS.

Note: Please ensure your cable is Thunderbolt™ 3 certified.

Tested in QNAP Labs. Figures may vary by environment.

Test Environment:
NAS: TVS-1582TU
Intel® Core™ i7-7700 3.60GHz CPU, 32GB RAM, Intel SSDSC2BB240G4 (SATA) x 15, RAID 5

Host: MacBook Pro
Intel® Core™ i7 2.9GHz CPU, macOS Sierra Version 10.12.3, 16GB 2133MHz LPDDR3

Host: MSI GS63VR 6RF Stealth Pro (Turbo mode)
Intel® Core™ i7-6700HQ 2.60GHz CPU, Windows 10 64-bit, 32GB RAM

A reliable NAS solution for SNG/OB van live production

TV and film productions and outdoor broadcasting require on-location recording, and need their videos to be backed up immediately to prevent file loss. For live outdoor broadcasting of sporting events, concerts or seminars, the videos usually require on-site editing before sending to TV stations for broadcast. The rackmount TVS-1582TU can fit in a standard 19" rack to function well on a moving vehicle or in an outdoor media editing environment. Coupled with its Thunderbolt™ 3, 10GbE network and USB 3.1 ports for high-speed data transfer and backup tasks, the TVS-1582TU provides an ideal storage center for these working environments.

Highly-efficient media collaboration for Mac and Windows

The TVS-1582TU is a perfect match for Thunderbolt™ 3-capable MacBook Pro®, and is backward-compatible with Thunderbolt™ 2 devices via Thunderbolt 3 (USB-C) to Thunderbolt 2 converter. The higher bandwidth is especially suited for creative professionals and enthusiasts from photographers, filmmakers to graphic designers who focus more on 4K or 3D workflows. The latest Final Cut Pro® X 10.3 adds support for the SMB protocol, allowing you to easily store files in the TVS-1582TU and share files with Windows®, and other devices using Thunderbolt™, 10GbE or 1GbE connection. Up to 4 Thunderbolt™ devices can connect to the TVS-1582TU to process real-time video editing simultaneously without impacting NAS performance, while 4K videos can be directly displayed using the NAS HDMI output. The TVS-1582TU's large capacity potential provides an ideal storage solution with unmatched performance for high-resolution file storage and I/O-intensive tasks to increase productivity in multi-workstation environments.

» How to set up a performance-optimized network drives for Final Cut Pro X 10.2 and previous version

Note: Final Cut Pro X 10.3 (and later) supports file sharing using Samba on NAS

Robust and reliable hardware

The TVS-1582TU is a 15-bay hybrid storage solution supporting 3.5” hard drives and 2.5” hard drives/SSDs in one chassis. Businesses can create the most cost-effective storage by implementing suitable drives based on their needs.

1. 9x3.5" / 2.5" SATA slots

Supports SATA 6Gb/s hard drives and SSDs.

2. 6x2.5" SATA SSD slots

Used for caching or high-performance storage pools.

3. Hot swappable fans

Four hot-swappable and easily-replaceable 60mm cooling fans.

4. DDR4 2133 MHz memory

Supports four DDR4 RAM modules (up to 64GB RAM).

5. 7th-Gen Intel® Core™ processors

14nm 7th Generation Intel® Core™ i5/i7 multi-core processors, supports DDR4 RAM and PCIe Gen.3 per-lane throughput.

6. 4 x Gigabit Ethernet ports

Allows optimized network traffic distribution with Thunderbolt™ and 10GbE ports for diverse applications.

7. 1 x HDMI output

Supports 4K Ultra HD for displaying up to 3840 x 2160 for an excellent audiovisual experience.

8. 2 x10GbESFP+ ports

Boosts iSCSI/NFS/CIFS network transfer for virtualization applications, data backup/restoration and massive data transmission.

9. 4 x Thunderbolt™ 3 ports

Thunderbolt™ 3 provides up to 40 Gbps of bandwidth, allows USB Type-C devices, and supports USB 3.1 Gen2 for up to 10 Gb/s transfer speeds.

Perfect storage trio: tiered storage, application-based partitioning & network traffic distribution

The advanced hardware design of TVS-1582TU can facilitate optimized storage deployment based on different usage scenarios.

Tiered Storage

With Qtier Technology that empowers Auto Tiering, the TVS-1582TU can automatically move frequently-used "hot" data to high-performance SSD storage tiers and less-accessed "cold" data to lower-cost, higher-capacity SATA drives, making the TVS-1582TU an extremely efficient shared resource. Qtier now supports “On Demand Allocation Priority”, providing customizable flexibility to arrange tiered storage suited for your system environments and application demands.

Learn more: Qtier, SSD caching

Application-based Partitioning

Every application requires different performance. For example, Surveillance Station requires higher-priority access to storage to ensure the integrity of recordings, while normal transmission speeds are sufficient for file sharing. However, when multiple applications are running on the same storage media, the required throughput level cannot be guaranteed as the storage media is busy handling I/O requests from all of them. The TVS-1582TU supports SSD and SATA hard drives, and they can be configured as independent partitions for different applications, ensuring a sufficient throughput level for every application.

Network Traffic Distribution

With 1GbE ports, 10GbE ports and Thunderbolt™3 ports, the TVS-1582TU allows applications to use dedicated interfaces to meet network traffic distribution requirements. Network interfaces can also be easily managed with the Network & Virtual Switch app, which enables optimized network resources for TVS-1582TU, virtual machines and containerized apps. No matter if they are business organizations or individual users, they can effortlessly manage network connections by using the Network & Virtual Switch.

Optimize 4K workflows with 4K HDMI output

The TVS-1582TU supports4K @30Hz through HDMI output, providing great benefits for applications like video production/editing, industrial design and professional photography that demand on-image resolution and color realism as well as intensive media storage, transfer and display. While the rack-mountable TVS-1582TU makes it easily usable in SNG/OB vehicles, it provides a quality, efficient 4K storage environment for fast-paced media industries. Powered by 14nm 7th Generation Intel® multi-core processors with Intel® HD Graphics, the TVS-1582TU delivers superior real-time 4K (H.264) and 1080p video transcoding to convert videos to universal formats that can be smoothly played on PCs, mobile devices and Smart TVs.

Note:Which video formats support hardware acceleration?

Access 10GbE networks over Thunderbolt with Thunderbolt-to-Ethernet (T2E)

As Apple® computers do not natively support 10 Gigabit Ethernet, Mac® users previously needed to purchase a Thunderbolt-to-Ethernet adapter to connect to high-speed Ethernet networks. The innovative Thunderbolt-to-Ethernet (T2E) allows computers without Ethernet ports (such as MacBook Pro®) to access 10GbE network resources over a Thunderbolt™ connection to the TVS-1582TU. This saves users from having to buy adapters or converters and greatly streamlines the connectivity process.

Note: T2E transmission speed may be affected when using a virtual switch. QNAP aims to continue improving and optimizing T2E performance.

Thunderbolt™ 3/NAS/iSCSI SAN triple solution

The TVS-1582TU can simultaneously run general Ethernet services in addition to the Thunderbolt™ 3 network, completely independently and with no bandwidth interference. As an unmatched NAS that combines Thunderbolt™, NAS and iSCSI SAN into one box, the TVS-1582TU prevents the restriction of DAS connecting to only one device, and breaks the cost barrier for creating 10GbE high-speed network environments.

Thunderbolt™ NAS mode

Simply attach your computer to the TVS-1582TU with a Thunderbolt™ 3 cable, and you will find the TVS-1582TU in Finder/File Explorer with accessible shared folders available for you. It is plug-and-use, and completely simple.

Ethernet NAS mode

The TVS-1582TU also features Ethernet networking for flexible file sharing across multiple devices simultaneously using SMB/CIFS, AFP and NFS for sharing across Windows®, Mac® and Linux®/UNIX® networks. Use Qfinder Pro to find the TVS-1582TU attached to your computer, and you can find the Thunderbolt IP and Ethernet IP for file sharing based on your needs.

iSCSI SAN block-based mode

The TVS-1582TU supports iSCSI SAN configuration, while the Thunderbolt™ interface can contribute a lot to iSCSI SAN storage performance. After creating an iSCSI target on the TVS-1582TU, you can access the iSCSI with your computer* through Thunderbolt IP.

*iSCSI initiator for Mac: ATTO Xtend SAN or SNS globalSAN; for Windows: Microsoft iSCSI initiator.

Flexibly attach, share, and expand in 4 ways

With four Thunderbolt™ 3 ports on the TVS-1582TU, you can flexibly arrange the connection of your computer workstations with the TVS-1582TU and its storage expansion enclosures based on your needs.

High accessibility (Mac + JBOD)

Attach three Mac® workstations to the TVS-1582TU via Thunderbolt™ 3 ports for online video editing, while the remaining Thunderbolt™ 3 port is used for storage expansion by connecting up to six NAS expansion enclosures (TX-500P / TX-800P). You can also take advantage of the built-in 10GbE LAN card for multi-device file sharing over a 10GbE network at the same time.

Optimal collaboration (Mac + Mac)

When using multiple workstations to work together to speed up a project, you can connect each workstation separately to the Thunderbolt™ 3 ports on the TVS-1582TU to enjoy simultaneous, speedy video editing.

Dividing resources (Mac + NAS)

Large video production studios often require multiple servers to increase productivity with different workflow stages, such as capturing, editing, production, post-production, and dubbing. In this situation it can be helpful to daisy chain an additional 6 TVS-1582TU units to the original TVS-1582TU and arrange each NAS for dedicated workflow stages, while the other Thunderbolt™ 3 ports are connected to the workstations for smoothly accessing large-sized video files. Meanwhile, each TVS-1582TU allows file sharing with multiple devices through Gigabit or 10 Gigabit Ethernet network.

Seamless expansion (JBOD+JBOD)

Rest assured your massive files are safely stored in the TVS-1582TU which supports seamless capacity expansion to offer you abundant storage. You can connect multiple QNAP storage expansion enclosures to the TVS-1582TU through Thunderbolt™ 3 ports or USB ports to enjoy huge storage capacity, and share files via 10GbE network.

Learn more: 10GbE solution

A feature-rich NAS with QTS operating system

QTS – simple, powerful & intelligent

The intuitive QTS features a modern flat design to help you manage QNAP NAS easily. QTS provides an intelligent desktop, graphical dashboard, drag-and-drop icons and grouped shortcuts to make storage and file management extremely simple. You can even open multiple application windows to run multiple tasks concurrently, bringing greater operating efficiency. The built-in App Center contains install-on-demand apps to provide potentially limitless potential for the NAS.

Learn more: QTS, App Center

QRM+: Centralized management solution for networked computing devices

QRM+ is QNAP’s Centralized Management Solution, designed for IT teams, for networked computing devices. It provides a single-point solution to discover, map, monitor and manage all of the critical computing devices (including servers, PCs, and thin clients) in your network, and facilitates device discovery with the graphical topology diagram. QRM+ supports IPMI 2.0, provides remote KVM (Keyboard, Video, Mouse) for certain IPMI devices, and supports tracking every action using KVM recording and playback. Simply install QRMAgent on your Windows® and Linux® devices and you will see their system status on the QRM+ management interface. With centralized management using QRM+ on the TVS-1582TU, IT infrastructure and device security is enhanced while troubleshooting and network resource performance analysis is greatly simplified.

Learn more: QRM+

Integrated virtualization and container solutions

Virtualization Station allows you to host virtual machines (VM) on the TVS-1582TU and access them via a web browser or VNC. It supports multiple operating systems, fast VM creation, VM backup & restoration, VM import/export, snapshot, and Device Management for centrally managing VMs. The TVS-1582TU also features Container Station, integrates LXC and Docker® lightweight virtualization technologies, allowing you to operate multiple isolated Linux® systems on the NAS as well as download apps from the built-in Docker Hub Registry®. Containers Station also supports the QIoT Containers platform that helps quickly structure your IoT environment and deployment on your private IoT cloud.

Learn more: Virtualization Station, P2V, Container Station, QIoT Containers

Storage for comprehensive virtualization applications

The TVS-1582TU is a comprehensive iSCSI/IP-SAN storage solution, and supports VMware®, Citrix®, Microsoft® Hyper-V® and Windows Server® 2012 R2, benefiting flexible deployment and management in virtualization environments. The TVS-1582TU supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi server and Hyper-V respectively, and supports QNAP vSphere Client plug-in and QNAP SMI-S provider with enhanced operational efficiency and management in virtualization applications.

Learn more: Storage for virtualization

Comprehensive security

QNAP's full NAS encryption by volume-based technology effectively ensures data security by encrypting all of the files stored in the default shared folders on the TVS-1582TU. Besides AES 256-bit encryption for both volumes and shared folders, the TVS-1582TU also provides numerous security options, such as antivirus, encrypted access, IP blocking, 2-step verification, and more.

Learn more: Privilege & Security

Well-rounded backup & disaster recovery

The TVS-1582TU offers flexible backup solutions for Windows® and Mac® users, Volume/LUN snapshots (block-based LUN* and file-based LUN), Folder snapshot, Snapshot Replica and Clone, and disaster recovery solutions including RTRR, rsync and cloud storage backup (Amazon® Glacier, Azure™ Storage, Google Cloud Storage™, Google Drive™, Microsoft® OneDrive® for Business, Dropbox®, and more) are also included.

* Up to 256 snapshots per volume or LUN, and a maximum 1,024 snapshots per NAS. It is recommended to use block-based LUN snapshots.

Learn more: Hybrid Backup Sync, Data backup & Disaster recovery, Remote backup solutions, VM backup, Volume & LUN Snapshots

Simplify email management with QmailAgent

QmailAgent helps you centrally manage and switch between different email accounts. Besides composing, reading and organizing emails, you can even directly attach files from the TVS-1582TU when composing emails. The QmailClient companion app for iOS® and Android™ works alongside QmailAgent to provide convenient access to multiple email accounts from mobile devices. You can use QmailAgent together with Qsirch, which supports searching through the .eml files stored on the TVS-1582TU; or quickly send emails to people and groups by using the Qcontactz app.

Learn more: QmailAgent, Qcontactz, Qsirch

Fast data filing and searching to double your productivity

The TVS-1582TU provides Qfiling and Qsirch for effortlessly organizing and searching for files, providing you with a highly-efficient data storage center. Qfiling automates file organization - simply determine filing conditions, set a schedule, and files will be organized and archived based on your settings. The Qsirch full-text search tool features quick file searching and supports thumbnail previews, content abstract, keyword hints, and more. Both Qfiling and Qsirch provide huge productivity boosts that greatly reduce the time spent looking for files on the NAS, allowing you to focus on other tasks.

Learn more: Qfiling, Qsirch

Whole new QVR Pro surveillance solution

The TVS-1582TU supports QVR Pro (Beta) that integrates QNAP’s professional QVR system into the QTS operating system. You can arrange a dedicated, independent storage space for surveillance data on the NAS and leverage the advantages of scalability and storage manageability from QTS. QVR Pro features a flexible monitoring interface that allows adjusting the proportion and monitor view of IP cameras, supports an upgraded timeline feature that provides instant video search and quick view identification in live monitoring mode, and allows for monitoring views and playing back images without switching between windows. Additional functions like batch adding and editing cameras and searching for cameras across different LANs further save the cost and time in deploying and maintaining a complete surveillance system. With the newly-developed QUSBCam2 App, you can use a USB camera as an ONVIF network camera. Simply connect it to your TVS-1582TU, and you can view real-time images without installing any software. Through QVR Pro, you can even store recordings for playback, allowing you to build a surveillance system with minimum budget.

Learn more: QVR Pro

Flexibly expand storage capacity for massive data

Besides attaching QNAP expansion enclosures, the TVS-1582TU’s storage capacity can also be increased by using VJBOD. With VJBOD, the storage capacity of other QNAP NAS* can be used as virtual disks that can be mounted as local disks on the TVS-1582TU for shares, applications, or even creating another LUN. You can use the QTS Storage Manager to easily handle NAS capacity expansion and storage expansion enclosure management.

The maximum number of drives available by connecting QNAP expansion enclosures:

QNAP NAS Model RAID Expansion Enclosure No. of RAID
Expansion Enclosure
Total HDD No.
(NAS + Enclosure)
TVS-1582TU TX-800P* 6 63
5 55
4 47
3 39
2 31
1 23
TX-500P* 6 45
5 40
4 35
3 30
2 25
1 20
UX-1200U-RP *** 1 27
UX-800U-RP *** 1 23
UX-800P *** 1 23
UX-500P *** 1 20

*The remote QNAP NAS must support iSCSI and Storage Pools and use QTS 4.2.1 (or newer). Up to 8 remote NAS units can be mounted.
**Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter is required for connecting Thunderbolt™ 2 expansion enclosures.
***To expand the storage space with an UX expansion enclosure, please create a separate static volume or storage pool on the UX expansion unit.

Learn more: VJBOD, Storage Manager, QNAP expansion enclosure

Optional Accessories

Cables

CAB-TBT320M-40G-LINTES
Thunderbolt™ 3 cable (40 Gbps), 2m (Not included as standard)

CAB-TBT305M-40G-LINTES
Thunderbolt™ 3 cable (40 Gbps), 0.5m (Not included as standard)

CAB-DAC15M-SFPP-A02
SFP+ Direct attach cable, 1.5m

CAB-DAC30M-SFPP-DEC01
SFP+ Direct attach cable 3m

CAB-DAC50M-SFPP-DEC01
SFP+ Direct attach cable 5m
Rail kit

RAIL-A03-57
A03 series (Chassis) rail kit, max. load 57 kg
Storage expansion accessories

TX-800P
8-bay Thunderbolt™ 2 expansion enclosure

TX-500P
5-bay Thunderbolt™ 2 expansion enclosure

UX-1200U-RP
2U, 12-bay USB RAID expansion enclosure

UX-800U-RP
2U, 8-bay USB RAID expansion enclosure

UX-800P
Tower 8-bay USB RAID expansion enclosure

UX-500P
Tower 5-bay USB RAID expansion enclosure
RAM

RAM-16GDR4-LD-2133
16GB DDR4 RAM, 2133 MHz, UDIMM

RAM-8GDR4-LD-2133
8GB DDR4 RAM, 2133 MHz, UDIMM

RAM-4GDR4-LD-2133
4GB DDR4 RAM, 2133 MHz, UDIMM
LAN card

LAN-1G2T-I210
QNAP dual-port Gigabit RJ45 network expansion card

LAN-10G2T-X550
QNAP dual-port 10 Gigabit 10GBASE-T network expansion card

LAN-10G2SF-MLX
QNAP dual-port 10 Gigabit SFP+ network expansion card

LAN-40G2SF-MLX
QNAP dual-port 40 GbE network expansion card
