TS-809 Pro Specification
| CPU | Intel Processor Core 2 Duo 2.8 GHz |
| DRAM | 2GB DDRII RAM |
| Flash Memory | 128MB DOM |
| HDD | 8 x 2.5"/3.5" SATA I/II HDD NOTE:
|
| HDD Tray | 8 x Hot-swappable and lockable tray |
| LAN Port | 2 x Gigabit RJ-45 Ethernet port |
| LED Indicators | Status, LAN, USB, HDD 1, HDD 2, HDD 3, HDD 4, HDD 5, HDD 6, HDD 7, HDD8, USB, LAN |
| USB | 5 x USB 2.0 port (front: 1; back: 4) Supports USB printer, pen drive, USB hub, and USB UPS etc. |
| Buttons | System: Power button, USB One-Touch-Backup button, reset button |
| LCD Panel | Mono-LCD display with backlight and buttons for configuration |
| Alarm Buzzer | System warning |
| Form Factor | Tower |
| Dimensions | 270 (D) x 200 (W) x 298 (H) mm 10.63 (D) x 7.87 (W) x 11.73 (H) inch |
| Weight | Net weight: 8.1 kg Gross weight: 9.8 kg |
| Sound Level (dB) | Standby: 35.1dB In Operation: 37.7dB; 41dB in busy read & write In Operation without HDD installed: 34dB |
| Power Consumption (W) | sleep: 42W In Operation: 81W Power-off (in WOL mode): 2.25W with 8 x640GB HDD installed |
| Temperature | 0~40℃ |
| Humidity | 0~95% R.H. |
| Power Supply | Input: 100-240V AC, 47-63Hz, Output: 350W |
| Secure Design | K-lock security slot for theft prevention |
| VGA | Reserved for maintenance |
| Fan | 2 x 12 cm smart cooling fan |
 | |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
