1. IEEE 802.3 10Tx Ethernet
2. IEEE 802.3u 100Tx Fast Ethernet
3. IEEE 802.3ab 1000Base-T
4. IEEE 802.3ad Link aggregation for parallel links
5. IEEE 802.3z 1000Base-X
6. IEEE 802.3bz 2.5GBase-T (QGD-1602P Only)
7. IEEE 802.3bz 5GBase-T (QGD-1602P Only)
8. IEEE 802.3x Flow Control for Full Duplex
9. IEEE 802.1q Virtual LANs (VLAN)
10. IEEE 802.1p QoS Protocol for Traffic Prioritization
11. IEEE 802.3af/802.3at/802.3bt

1. HTTP/HTTPS Connection
2. Multi-window, multitasking system management
3. Smart toolbar and dashboard for system status display

1. Risk Assessment
2. Risk Management
3. Threat Analysis
4. Customizable Risk Inform Policy
5. Cyber-attacks trap
6. Exclusions & Port monitoring rule
7. Event notification
8. Log sender

1. Risk IP Management and Quarantine
2. Customized Protection Rules

1. Manager Port Configuration (DHCP/Static IP/PPPoE)
2. Jumbo frame support
3. VLAN support

1. MAC History
• Device scan
• Wake on LAN (WoL)
2. Port Management
• Port Status
• Port Statistics
• Port Configuration (State/Speed/Flow Control/Frame Size)
3. Power over Ethernet (PoE)
• Power Consumption
• Power Configuration (PoE Mode/Priority)
• PoE Schedule
4. VLAN
• IEEE 802.1Q Tag-based VLAN
5. Link Aggregation
• LACP/Static Mode
6. IGMP Snooping
• IGMP Snooping Configuration (State
• IGMP Snooping Statistics
7. Quality of Service (QoS)
• QoS Mode (Port-based/VLAN-based)
8. MAC Address Table
9. Link Layer Discovery Protocol (LLDP)
10. Loop Protection
11. SNMP (v2c/v3)

1. System Volume
2. Application Volume
• RAID Type: RAID 1 (2 Disks)
3. Disk Information & SMART Information
4. Disk SMART Test & SMART Test Schedule
5. Disk bad block scan and recovery

1. myQNAPmyQNAPcloud Link for remote access without complex router setup
2. DDNS for free url registration
3. SSL Certificate for registered url

1. Event Log/Access Log
2. Online Users
3. Log Entries Setting/Log Retention Time Setting/Log Language Setting
4. Log Sender/Log Receiver
5. 23 language support

1. Notification Queue & History
2. Notification Sending Method
• E-mail (Gmail, Yahoo, QQ, Outlook…etc)
• SMS (Nexmo, Twilio, Clickatell…etc)
• Instant Messaging (QNAP Bot)
• Push Service (Qmanager)
3. Notification Setting Rule

1. System Resources
• CPU/Memory/Network
2. Storage Resources
• Volumes/Status/Storage usage
3. Processes activity

1. Certificate & Private Key
• Replace Certificate & Download Certificate
2. Password Policy
• Password Strength Rule
• Password Change Periodical Rule
3. Anti-tampering for system
4. Security Checkup

1. License on Device
• License Status/Activate License/Purchase License
2. Recover License
3. Software Store
4. License Manager

1. System
• General Settings
• Hardware
• Power
• System Update
• Backup/Restore
• UPS
• System Status
2. Privilege
• Users Management
3. Services
• SSH Server
• SNMP Service (V1/V2/V3)
• UPnP Discovery Service
• Bonjor

1. Help Request
2. Remote Support
3. Diagnostic Tool

QNE ADRA (embedded Linux)

1. Apple Mac OS 10.7 or later
2. Linux and UNIX
3. Microsoft Windows 7, 8, 10, and 11 or later
4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, and 2022 or later

1. Apple Safari 7 or later
2. Google Chrome
3. Microsoft Internet Explorer 10 or later
4. Mozilla Firefox

1. Chinese (traditional and simplified), Czech
2. Danish, Dutch
3. English
4. Finnish, French
5. German, Greek
6. Hungarian
7. Italian
8. Japanese
9. Korean
10. Norwegian
11. Polish, Portuguese (Brazil)
12. Romanian, Russian
13. Spanish, Swedish
14. Thai, and Turkish

Internal hard drive (EXT4)

1. IEEE 802.3 10Tx Ethernet
2. IEEE 802.3u 100Tx Fast Ethernet
3. IEEE 802.3ab 1000Base-T
4. IEEE 802.3ad Link aggregation for parallel links
5. IEEE 802.3z 1000Base-X
6. IEEE 802.3x Flow Control for Full Duplex
7. IEEE 802.1q Virtual LANs (VLAN)
8. IEEE 802.1p QoS Protocol for Traffic Prioritization
9. IEEE 802.3af/802.3at/802.3bt

1. Port status
2. Port statistics
3. Port configuration
4. Jumbo frame support
5. IEEE 802.3x flow control
6. Auto-negotiation of speed and duplex modes

1. Power consumption status
2. Power configuration: PoE mode selection, Priority
3. PoE schedule

1. Bandwidth control
2. Traffic classification
3. Rate limiting

1. VLAN configuration
2. Port-based private VLAN
3. IEEE 802.1Q-based VLAN

1. Port trunking
2. LACP groups
3. IGMP snooping v2
4. Loop protection to avoid broadcast loops

1. Access Control Lists (ACL): ACL by IP address, ACL by MAC
2. Network access protection with auto-blocking (SSH, Telnet, HTTP(S), FTP, CIFS/SMB, and AFP)
3. Host access control for shared folders (CIFS/SMB)
4. AES 256-bit folder-based and volume-based encryptions, which are validated by FIPS 140-2 Cryptographic Algorithm Validation Program (CAVP )
5. 256-bit external drive encryption (AES)
6. Import SSL certificates from Let’s Encrypt
7. Instant alerts through email, SMS, push service, audio, and LCD panel
8. 2-step verification

1. Link Layer Discovery Protocol (LLDP): LLDP remote device
2. Interfaces: Web UI, telnet, Command Line Interface (CLI)
3. SNTP, DNS, DHCP client entry
4. Port mirroring
5. Wake-on-LAN
6. Static MAC address

QTS 4.4.1 (embedded Linux)

1. Apple Mac OS 10.7 or later
2. Linux and UNIX
3. Microsoft Windows 7, 8, and 10
4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016

1. Apple Safari 7 or later
2. Google Chrome
3. Mozilla Firefox

Chinese (traditional and simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, and Turkish

1. Internal hard drive (EXT4)
2. External hard drive (EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT)
   Note: To use exFat you must purchase an exFAT driver license from License Center.

1. TCP/IP: Dual stack (IPv4 and IPv6)
2. Jumbo frame
3. DHCP server and client
4. RADVD
5. USB Wi-Fi adapter
   Note: This feature does not support ad hoc networks because of security concerns.
6. USB QuickAccess
7. Static Route
8. Network Connectivity Status Indicator (NCSI)
9. DDNS settings (Customize and Multiple Services)
10. Port trunking (Link aggregation)
• Failover
• Load balancing
11. Virtual switch
• Network Address Translation (NAT)
• Spanning Tree Protocol (STP)
• Guardian vSwitch Mode

1. HTTP/HTTPS Connections
2. Supports WebDAV Connections
3. Supports Virtual Hosts (Max: 32)
4. Importable SSL Certificates

1. RAID Hot Spare and Global Hot Spare
2. RAID Rebuild Speed Customization
3. Online RAID capacity expansion
4. Online RAID level migration
5. SSD RAID Over-provisioning
   Note: RAID 0 and JBOD data RAID does not support over-provisioning.
6. SSD RAID performance evaluation (with SSD profiling tool)
7. Bitmap support
8. Disk auto S.M.A.R.T. data migration
9. Disk bad block scan and recovery
10. Disk S.M.A.R.T test
11. Disk secure data erase
12. Ironwolf Health Management
13. Storage pools
14. Qtier™ data tiering technology
15. Online volume expansion
16. Volume type conversion
17. Volume shrink
18. Storage space utilization
19. Storage expansion using QNAP expansion units
20. JBOD enclosure roaming
21. Supported RAID types
• 2-bay: RAID 0, 1, JBOD, Single
22. Snapshots
• Volume and LUN snapshots
• Snapshot Dashboard
• Snapshot Manager
• Snapshot local restore and revert
• Snapshot Clone
• Snapshot Replica and Snapshot Vault
• Snapshot remote restore and revert
• Unified Snapshot Directory
• Supports Windows Previous Versions (CIFS/SMB)
• Snapshot Agent for Microsoft Windows and VMware vSphere
  Note: This feature requires at least 1 GB of memory. The maximum number of snapshots varies according to installed memory.
23. Flexible volumes and LUNs with thin provisioning and space reclaiming
• If the NAS has less than 4GB RAM, then the maximum volume capacity is 144TB.
• If the NAS has at least 4GB RAM, then the maximum volume capacity is 250TB.

1. iSCSI targets with multiple LUNs per target
   Note: The maximum number of targets + LUN is 256.
2. LUN mapping and masking
3. Online LUN capacity expansion
4. SPC-3 persistent reservation
5. MPIO & MC/S
6. iSCSI LUN backup, one-time snapshot, and restoration
7. Virtual disks using iSCSI initiator
   Note: The maximum number of virtual disks is eight.
8. Stack chaining master

1. Added support for sending notifications via SMS providers, including Nexmo, Twilio, and Clickatell.
2. Added Outlook as an SMTP service option.
3. Added support for sending notifications via instant messaging applications, including Skype and Facebook Messenger.
4. Added support for Overview and History in Notification Center.
5. Added 23 language support for notification messages.
6. Added support for creating custom notification rules to specify notification criteria, including application categories, severity levels, and keywords.
7. Delivery method and message recipient settings are now more flexible.
8. Added support for creating multiple notification rules at the same time.
9. Added support for sending notifications for a single system event.

1. Multiple user creation
2. User data importing and exporting
3. User quota management
4. Local user access control (AFP, CIFS/SMB, FTP, and WebDAV)
5. Application access control (File Station, Music Station, Photo Station, and Video Station)
6. Subfolder permissions (AFP, CIFS/SMB, FTP, and File Station)

1. Microsoft Active Directory (AD) and domain controller support
2. LDAP server and client
3. Domain user login (AFP, CIFS/SMB, FTP, and File Station)

1. Free host name registration (DDNS)
2. Optional myQNAPcloud SSL certificates (DDNS)
3. Auto-router configuration using UPnP
4. Web-based file manager with HTTPS 2048-bit encryption
5. myQNAPcloud Link for remote access without complex router setup

1. File syncing across multiple devices with SSL secure connection
2. Selective synchronization for specific folders or subfolders
3. Set up team folders as file centers for better collaboration
4. Share file using email links
5. Configure policies for conflicting files and file type filter
6. Supports up to 64 versions for version control
7. Unified privilege and configuration management
8. Central configuration mode
9. Remote erase and restore
10. Qsync client supported platforms: Windows, Mac, Ubuntu, and Android

1. Monitor NAS system resources, including CPU, memory and network
2. Monitor NAS storage resources, including volumes, RAID, and disk activity
3. Monitor NAS application resource usage
4. Create extra swap space when SSDs are installed

1. Report issues to the QNAP support team through automatic system information collection
2. Remote connection between QNAP support engineers and NAS for issue resolution (with user permission)

1. Multi-window, multitasking system management
2. Smart toolbar and dashboard for system status display
3. SNMP versions 2 and 3
4. Resource monitor
5. Comprehensive logs (events and connections)
6. Syslog server and client
7. Backup and restoration of system settings
8. Qmanager: Mobile application for remote system monitoring and management
9. Qboost
10. Network recycle bin
• Recover files deleted using AFP, CIFS/SMB, and File Station
• Automatic cleanup
• File type filter

1. File sharing across Windows, Mac, and Linux/UNIX
2. Microsoft networking
3. Apple networking
4. NFS service
5. Windows ACL (CIFS/SMB)
6. Advanced folder permissions (AFP, CIFS/SMB, and FTP)
7. Shared folder aggregation (CIFS/SMB)

1. FTP over SSL/TLS (explicit)
2. FXP support

1. Cloud drive mounting for Google Drive, Dropbox, Microsoft OneDrive, Microsoft OneDrive for Business, HiDrive, Amazon Cloud Drive, Yandex Disk and Box
2. Remote shared folder mounting (CIFS/SMB, FTP, and WebDAV)
3. Document viewing using Office Online, Google Docs, and Chrome extension
4. Microsoft Office file editing using Google Docs, Sheets, and Slides
5. ISO file mounting (maximum: 256 ISO files)
6. Mount smart phones as external storage
7. Read access for compatible optical disc drives
8. Read access for compatible smartphones with Media Transfer Protocol (MTP)
9. Download and upload link sharing
10. File dragging and dropping (Chrome and Firefox)
11. Preview and playback photos, video, and music with hardware-accelerated transcoding
12. File compression (ZIP and 7z)
13. Create download links and send publicly shared files, with expiration date and password protection
14. Subtitle display (SRT and UTF-8)
15. Video seeking during on-the-fly transcoding video playback
16. Slideshow playback in media viewer
17. Convert image files to pdf by “Image2PDF” integration
18. Qfile: Mobile app for file browsing and management

1. Auto filing
2. Recipe function
3. Archiving through iSCSI, USB, DVD and remote NAS
4. Advanced settings
• Source File Filters
• File Editing
• File deletion
• Data integrity check
• File conflict policy

1. Supports cloud storage backup to the following services : Amazon Glacier, Amazon S3, Azure Storage, Google Cloud Storage, HKT Object Storage, OpenStack Swift, and WebDAV
2. Supports cloud storage syncing with the following services: Alibaba Cloud, Amazon Drive, Amazon S3, BackBlaze B2, Box, Dropbox, OneDrive, Google Drive, HiDrive, hubiC, OneDrive, OneDrive For Business, ShareFile, Yandex.Disk
3. RTRR server and client with bandwidth control
4. Rsync server with download bandwidth control
5. Remote server syncing (CIFS/SMB, FTP, Rsync, and RTRR)
6. Scheduled backup to local and remote storage spaces
7. Backup versioning (RTRR)
8. Encryption, compression, and file filters
9. Centralized management for backup, restoration, and sync jobs
10. Supports Apple Time Machine
11. Backup data to multiple external storage devices
12. Backup desktops with QNAP NetBak Replicator for Windows
13. Supports the following third-party backup software: Veeam Backup & Replication, Acronis True Image, Arcserve Backup, Retrospect, Nakivo Backup & Replication, and Veritas Backup Exec

1. Virtual machine creation (Windows, Linux, Unix, and Android)
2. Virtual machines import, export, clone, snapshot capture, backup, and restore
3. Console displays using HDMI output (QVM) export
4. HTML5-based shared remote console
5. Various networking modes and virtual switch support

1. LXC and Docker support
2. Built-in Docker Hub Registry for app downloads
3. One-click installation
4. Container import and export
5. Console mode
   Three networking modes (Note: Docker containers support Bridge, NAT, and Host modes. Linux containers (LXC) only support NAT.)
6. Container auto-start
7. Downloadable Docker certificate
8. Private registry
9. Application repository for switching to any repository on GitHub.com

1. Full-text search
2. Data distribution using a bar chart
3. Previews for photos, music, videos, PDFs, Gmail, and others
4. Advanced search operators and search scope
5. Customized search filters with included or excluded conditions
6. Related files suggestion in Viewer
7. Search Chrome, Firefox and Safari extension

Note: This feature is supported by all QNAP NAS devices with at least 2 GB of memory (excluding the TAS series)

1. All models include 8 built-in licensed camera channels
2. Scale up to 16 camera channels
   (QVR Pro Gold license required)
   Note: The maximum number of channels supported varies according to NAS model, network configuration, and camera settings. For more information, visit https://www.qnap.com/go/qvr-nas-selector.
3. QVR Pro as motion detector support
4. Different network camera management
5. Dedicated recording spaces pre-allocation
6. User-defined trigger events and corresponding actions
7. Quick search with data sources paired with cameras
8. Assign network interfaces to each camera for recording sessions
9. RTSP and WebRTC support
10. Import and export camera connection information in CSV file format
11. View live and recorded surveillance video with QVR Pro Client
12. QVR Pro configuration files daily auto backup
13. Recording import support
14. Record H.264/H.265 camera video streams support

1. Instantly switch between Live and Playback modes
2. Dynamic and adjustable layouts for camera and E-map views
3. Qdewarp technique for dewarping fisheye and 360-degree cameras
4. Region of interest in each channel
5. Add and edit cameras on QVR Pro Client support
6. Hardware acceleration for fisheye cameras
7. Video wall (up to 8 monitors)
8. Hardware acceleration on Windows, Mac, Ubuntu, and HybridDesk Station
9. Multithreaded decoding
10. Synchronized video playback
11. Specifying exported recordings on the timeline support
12. Virtual keyboard (for HybridDesk Station version)
13. Playback deleted channel recordings support
14. Receive notification messages about system time zone changes in QVR Pro
15. Server dashboard (when connected to QVR Center)
16. Playback control via the keyboard (space and arrow keys)
17. Display camera location and event notifications on e-maps support
18. Export file format selection support
19. 2-step verification support
20. Cross-platform support: Windows, macOS, Ubuntu, QNAP HybridDesk Station

1. Instantly switch between Live and Playback modes
2. Cross-platform support: Android and iOS
3. Various advanced monitoring options: sequential mode, PTZ control, auto cruising, and preset point control
4. Instant push notifications support
5. Display camera locations on e-maps support
6. Server dashboard displaying NAS information, camera status, and recording space status

1. Supports management of up to 128 QVR Pro servers (QVR Pro Gold license required)
2. Statistical graphics for visualizing event data
3. Log management for all added servers
4. Integration with QVR Pro Client for central monitoring across multiple servers
5. Centralized view using cameras from multiple servers
6. Backward compatibility with Surveillance Station and VioStor NVR

1. Failover solution designed for QVR Pro to ensure server availability
2. Viewing task details during the failover period
3. Automatic switch between Standby and Takeover modes based on QVR Pro server status

More camera manufacturers and models support
Note: To download the Camera Package, go to QVR Pro Plug-in Center.

1. USB webcams as ONVIF IP cameras (remotely manageable) configuration
2. Live views (no other apps required) monitor
3. RTSP support

1. Supports up to 5,000 IP cameras
2. Four free camera licenses
   Note: Surveillance Station supports a maximum of 16 camera channels. To add more camera channels, you need to purchase licenses from the QNAP License Store.
3. Instant playback of recent surveillance events
4. Visual options for e-maps
5. Playback speed control
6. Display preview snapshots on the timeline support
7. Intelligent Video Analytics (IVA) for advanced video searches
8. Surveillance client designed for macOS
9. Mobile surveillance application (Vmobile) for iOS and Android
10. Mobile recording application (Vcam) for iOS and Android

1. Utility and mobile apps for Windows, Mac OS, and Android support
2. VPN server
• User-friendly graphical overview page
• Secure remote access with PPTP, L2TP/IPSec, OpenVPN, QBelt (QNAP proprietary) protocol
• Supports a maximum of 100 clients
• Public, NAS default, and manually DNS server support
• Manually assign, auto detect, and none outgoing network interface support
• Privilege settings for domain and local users support
3. VPN client
• PPTP, L2TP, IPSec, OpenVPN, and QBelt (QNAP proprietary) protocol support
• VPN as a NAS default gateway support
• Connection log check support

1. Monitor multiple NAS devices
2. Utilization reports
3. Unified configuration management
4. Monitor NAS devices behind NAT routers with Connect to Q’center
   Note: The application is available in the App Center and in virtual appliance marketplaces (VMware vSphere ESXi and Microsoft Hyper-V).

1. Find QNAP NAS location on the same local network
2. NAS shared folder mounting
3. Configure basic settings (firmware, SMTP server, and network settings)
4. Direct connection with USB QuickAccess and Thunderbolt (specific models only)
5. Storage Plug and Connect (Windows only)
• Create and map NAS shared folders
• Create and connect iSCSI targets and LUNs
6. Media upload (Windows only)
• Upload media files to the NAS
• Automatically create thumbnails or video transcoding with computers

1. Official and community software add-ons
2. Automatic updates and new version notifications
3. Repository for imported third-party content
4. User-specified volume for storing applications

1. Insert Evernote Notes in Notes Station 3
2. Enable YouTube video embedding in Notes
3. Create tables with insert table editor

1. Chrome and Firefox support
2. International keyboards and mouse input support
3. User login permissions

1. NAS as a Linux-based computer support
2. Ubuntu 14.04, Ubuntu 16.04, and Ubuntu Kylin 16.04 support
3. Ubuntu Software Center app downloads
4. Remote desktop for Ubuntu remote monitor and access
   Note: The application requires at least 4 GB of memory and installation of Container Station.

1. One-way scheduled sync of contacts from multiple Google accounts
2. Import and export contacts from CSV or vCard 3.0 files
3. Duplicate contact search and merge
4. Contact management: Groups, favorites, lock, search, delete and restore
5. Cross-platform support: Android and iOS

1. Designs and specifications are subject to change without notice.
2. Some features may vary according to model.
3. QTS does not support DRM content and some IPv6 services.
4. Some data encryption features may be unavailable because of country-specific legislative restrictions.

1. Telnet
2. Support for wireless ad hoc networks

Note: The following features are deprecated, but will continue to function until complete removal in future releases. QNAP recommends users to plan ahead or use alternative solutions prior to the complete removal of these features.

1. Launch IoT applications quickly with little human involvement
2. Supports multiple protocols (MQTT, HTTP and CoAP) and dashboards, allowing for the quick connection of development boards along with multiple sensors
3. Flexible workflow creations with graphical rules engine drag-and-drop blocks and connection nodes feature
4. Important information of connected IoT devices with customizable dashboards monitor
5. Benefit from the integration of private and public clouds

1. Responds to local events in near real-time
2. Operate offline
3. Secure communication
4. Simplified device programming with AWS Lambda
5. Reduces costs of running IoT applications

1. Centralized Remote Management solution designed for IT Teams in industries reliant on networked computing devices
2. Remote Management of Windows, Linux, and IPMI compatible devices
3. Offers threshold based alerts to fix performance problems before impacting users, applications, and businesses
4. Supports multiple active monitors, including CPU Utilization, Memory Utilization, Disk Utilization, CPU Temperature, CPU Fan speed, and more, providing complete visibility for administrators across all mission critical computing devices
5. Benefit from higher productivity, better collaboration, and faster recovery from device downtime or system performance
6. Android mobile app support

1. Multiple security policies (Basic/Intermediate/Advanced/Custom
2. Check NAS settings for security vulnerabilities
3. Existing anti-virus services integration
4. Existing anti-malware services integration
5. Security Advisory service integration

Malware detection and removal
