QSW-3205-5T Specification
-
QSW-3205-5T
Administrationstype Ikke-administreret Antal porte 5 10 GbE BASE-T (RJ45) 5 10 G/5 G/2,5 G/1 G/100 MStrømforsyningsbeskrivelse Adapter Maks. strømforbrug 36 W Inputstrømtype DC Inputspændingsområde 12 V/3 A MAC-adressetabel 16K Samlet ikke-blokerende hastighed 50Gbps Switching-kapacitet 100 Gbps Energieffektivt Ethernet (overholder IEEE 802.3az) Uden blæser Understøttede standarder IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5G/5GBase-T
IEEE 802.3an 10GBASE-T
IEEE 802.3az EEE
IEEE 802.3x Fullduplex flowkontrolFormfaktor Desktop LED-indikatorer Per port: Hastighed/Link/Aktivitet
Per system: Strøm/Status/LoopMål (HxBxD) 34 x 180 x 145 mm Vægt (netto) 0.96 kg Vægt (brutto) 1.2 kg Driftstemperatur 0 °C til 40 °C (32 °F til 104 °F) Relativ luftfugtighed 10~95% Ikke-kondenserende Certificeringer CE, UKCA, FCC, IC, VCCI, RCM, BSMI, LVD, KC Elektromagnetisk overensstemmelse CLASS A Jumbo-rammer 12k Garanti 2 år Note: QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
QSW-3205-5T
Power supply
Bracket screws
Anchors
Foot pads
Quick Installation Guide (QIG)
Bundled accessories delivered together with the product such as expansion cards, power adapter, and accessories are covered with one-year warranty.
