TS-253A
QTS-Linux Combo NAS: a well-rounded private cloud solution centralizing storage and IoT applications
Home > Product overview > SMB > Mid-range > TS-x53A Series > TS-253A
Features Specification Utilities Popular downloads
Ordering P/N TS-253A-4G | TS-253A-8G
CPU 14 nm Intel® Celeron® N3150/N3160 1.6 GHz quad-core processor
Floating Point Unit
Hardware Encryption
✔ (AES-NI)
GPU 8th generation Intel HD Graphics
System memory TS-253A-4G: 4GB (2 x 2GB)
TS-253A-8G: 8GB (2 x 4GB)
Memory Expandable Up To 8 GB
Total Memory Slots 2, SODIMM DDR3L-1600
(*For dual-DIMM configurations, you must use a pair of identical DDR3L modules.)
Flash Memory 512MB
Maximum Number of Hard Drive 2
Hard Disk Drive Hot-swappable 3.5" or 2.5" SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
LAN Port 2 x Gigabit RJ-45 Ethernet port
USB 4 x USB 3.0 port (Front:1, Rear:3)
Support USB printer, pen drive, and USB UPS etc.
Video Output 2 x HDMI, up to 4K 2160P 30Hz Ultra HD support
Audio Input 2 x 6.3mm microphone jacks (dynamic microphones only)
Audio Output Line Out Jack (for amplifier or headphone amplifier)
LED Indicators Status, USB, HDD 1-2
Buttons System: Power button, USB one-touch-backup button, Reset button
IR Receiver ✔, Support QNAP RM-IR002, RM-IR003 and MCE-compatible Remote Control
Other Interface Kensington security slot, console port (system maintenance)
Alarm Buzzer System warning
Form Factor Tower
Dimensions 150(H) x 102(W) x 216(D) mm
5.91(H) x 4.02(W) x 8.5(D) inch
Weight Net: 1.74 kg (3.84 lbs)
Gross: 2.92 kg (6.44 lbs)
Power Consumption (W) System sleep mode: 1.18W
HDD standby: 8.38W
In operation: 14.43W
Sound Level* Sound pressure (LpAm) :18.3 dB(A)
Temperature 0-40˚C
Relative Humidity 5~95% RH non-condensing, wet bulb: 27˚C
Power Supply 65W AC adapter, 100-240V
Fan 7cm quiet cooling fan (12V DC)

* Testing Environment:
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS



Designs and specifications are subject to change without notice.
