QSW-M2116P-2T2S

QSW-M2116P-2T2S Specification


Administrationstype	Webadministreret
Antal porte	20
10 GbE SFP+	2
10 GbE BASE-T (RJ45)	2
2.5GbE (RJ45)	16
PoE-porte i alt	18
PoE PSE (802.3af, 15,4 W)	Port 1-16
PoE+ PSE (802.3at, 30 W)	Port 1-16
PoE++ PSE (802.3bt, 90 W)	Port 19-20
PoE-strømoutput	Port 1-16 (30 W), Port 19-20 (90 W)
Samlet PoE-strømbudget	280 W
Strømforsyningsbeskrivelse	Intern strømforsyning
Maks. strømforbrug	350 W
Inputstrømtype	AC
Inputspændingsområde	100-240 VAC, 50/60 Hz
MAC-adressetabel	32K
Samlet ikke-blokerende hastighed	80 Gbps
Switching-kapacitet	160 Gbps
Administrationsbrugergrænseflade	Web
Konsol	RJ45
Blæser	Blæser med dobbelt PWM-kugleleje x 2
Understøttede standarder	IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-SX/LX IEEE 802.3an 10G BASE-T IEEE 802.3ae 10G Fiber IEEE 802.3x Fullduplex flowkontrol IEEE 802.1Q VLAN Tagging IEEE 802.3ad LACP IEEE 802.1AB LLDP IEEE 802.3af/at/bt Power-over-Ethernet (PoE)
Formfaktor	Rackmontering
LED-indikatorer	Per port: Hastighed/Link/Aktivitet Per system: Status/PoE/Blæser
Knapper	Nulstillingsknap
Mål (HxBxD)	43.5 x 285 x 234.8 mm
Vægt (netto)	2.08 kg
Vægt (brutto)	2.13 kg
Driftstemperatur	0 °C til 40 °C (32 °F til 104 °F)
Relativ luftfugtighed	5~95 % ikke-kondenserende
Certificeringer	CE, FCC, VCCI, BSMI
Elektromagnetisk overensstemmelse	CLASS A
Jumbo-rammer	9k
Garanti	2 år

Note: QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.

Standards Compliance	IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5G/5GBase-T IEEE 802.3an 10G BASE-T IEEE 802.3z 1000BASE-SX/LX IEEE 802.3ae 10G Fiber IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.3ad LACP IEEE 802.1AB LLDP IEEE 802.3af/at/bt Power over Ethernet(PoE) Show more...
Port Management	Port status Port statistics Port configuration Jumbo frame support IEEE 802.3x flow control Auto-negotiation of speed and duplex modes Show more...
PoE	Power consumption monitor Port configuration PoE scheduling
VLAN	VLAN configuration IEEE 802.1Q-based VLAN
Layer 2 Features	LACP IGMP snooping v2
QoS	Port-based QoS VLAN-based QoS
Traffic	MAC address table Rate limit
Security	Access Control Lists (ACL): ACL by IP address
Firmware management	Firmware Live Update Firmware Manual Update
Other Features	Link Layer Discovery Protocol (LLDP): LLDP remote device Interface: Web UI SNTP, DNS, DHCP client entry Loop protection Port mirror Show more...
