QMiro-201W

QMiro-201W Specification


Antal Ethernet-porte	2
1 GbE (RJ45)	2
CPU	Qualcomm IPQ4019, Quad 4 kerner ARM Cortex A7@716,8 MHz
Hukommelse	512 MB DDR3
Flash Memory	4 MB SPI NOR Flash 4 GB eMMC
Trådløs antenne	4 interne antenner
Trådløs standard	802.11a/b/g/n/ac
Trådløs hastighedsklassificering	AC2200
Trådløs hastighed 2,4 GHz	2.4G (400Mbps): 2x2 Dual Band(20/40MHz)
Trådløs hastighed 5 GHz	5G (867+867Mbps): 2x2 Dual Band(20/40/80MHz), 2x2 Single Band(20/40/80MHz)
Frekvensbånd 2,4 GHz
Frekvensbånd 5 GHZ
Trådløs båndbredde	20/40/80 MHz
Transmissionsoutputeffekt	Afhænger af landekode
Trådløs antennetype	2 interne dual band(2.4G/5G) antenner 2 interne single band(5G) antenner
Antenneforstærkning 2,4 GHz	4,6 dBi, 2.7 dBi
Antenneforstærkning 5 GHz	4,9 dBi, 6,0 dBi
Transmissionseffekt	24 dBm
Wi-Fi 5 (802.11ac)
USB 3.2 Gen 1-port	1 Kun til tilslutning af USB-dongle-lager til FTP-service på routeren
Bluetooth	Version 5
Bluetooth-antenneforstærkning	2,3 dBi
Knap	Nulstil, WPS
Strøm	12 V DC
Strømforbrug	24 W
Mål	68 x 100 x 175,5 mm
Vægt	0,44 kg
Pakkevægt	1,11 kg
Driftstemperatur	0°C ~ +40°C
Driftsluftfugtighed	5 % til 95 % ikke-kondenserende
Certificeringer	JATE / CE / FCC / BSMI / NCC / IC / SRRC / VCCI / RCM / OFCA
Wi-Fi Mesh	(med Tri-Band)
QNAP SD-WAN-løsning, QuWAN

Note: QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.

System Status and Management	Device connection status Device health status WAN status Wireless status Firmware schedule management Show more...
Operation Modes	Wireless router mode Access point (AP) mode
Wired Network Management	WAN port x1 DHCP client PPPoE Static IP LAN port x 1 DHCP server Reserved IP table Show more...
Wireless Network Management	Supports IEEE 802.11ac (Wi-Fi 5) Supports MU-MIMO Supports band steering for dual-band (2.4GHz and 5GHz bandwidth) access points Transmission power (high, middle, and low) 20/40/80 MHz bandwidth RTS/CTS (Request to Send/Clear to Send) function Dual-band 2.4G and 5G band settings Guest wireless Smart connect SSID and password configuration Wireless scheduler Wireless (Protected Setup (WPS) Show more...
WiFi Mesh	Support up to 4 device(1 master 3 satellites per mesh system) Tri-band Add/delete node
IPv4 routing management	Direct route Static route
NAT	Port forwarding and Network Address Translation (NAT) Support FTP ALG, PPTP ALG and SIP ALG
QVPN	Secure remote access with L2TP, OpenVPN and QBelt (QNAP proprietary) protocol Client IP pool configuration VPN client management Connection logs Maximum tunnel scale: 30 Show more...
Parental Controls	Website filter Safe search Youtube Google Bing Show more...
System Setting	Restart, Reset, Backup, Audio Alert Local account, QNAP ID, Remote management Even Logs
Firmware	Firmware update Live update Schedule update Manual update Display mesh nodes firmware status Show more...
QuWAN SD-WAN Service	Auto multi-site VPN WAN optimization WAN aggregation Failover Load Balance Traffic monitoring using QuWAN Orchestrator Show more...
QuRouter APP supported	Managed QMiro-201W Create WiFi mesh Add/delete Wifi mesh node
