TES-1885U Specification

TES-1885U
Specification
Buy→

  1. TES-1885U-D1521-8GR (Legacy)
    CPU Intel® Xeon® D-1521 4-core 2.4 GHz processor, Max turbo to 2.7 GHz.
    CPU Architecture 64-bit x86
    Floating Point Unit
    Encryption Engine (AES-NI)
    System Memory 8 GB RDIMM DDR4 ECC (1 x 8GB)
    Maximum Memory UDIMM: 64 GB (4 x 16 GB)
    RDIMM: 128GB (4 x 32 GB)
    Memory Slot 4 x RDIMM DDR4
    32 GB (above) RAM is required for QES operating system.
    You can only use one type of dual in-line memory module (DIMM) at a time. Do not use registered DIMM (RDIMM) with unbuffer DIMM (UDIMM) memory.
    Flash Memory 4GB (DOM for dual OS)
    Drive Bay Front: 12 x 3.5-inch
    Rear: 6 x 2.5-inch
    Drive Compatibility 3.5-inch bays:
    3.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA solid state drives

    2.5-inch bays:
    2.5-inch SATA solid state drives
    Hot-swappable
    SSD Cache Acceleration Support
    GPU pass-through
    Gigabit Ethernet Port (RJ45) 4
    10 Gigabit Ethernet Port 2 x 10GbE SFP+
    Wake on LAN (WOL)
    Jumbo Frame
    PCIe Slot 4
    Slot 1: PCIe Gen 3 x8
    Slot 2: PCIe Gen 2 x4
    Slot 3: PCIe Gen 3 x4
    Slot 4: PCIe Gen 3 x4 or PCIe Gen 3 x8
    Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3.
    USB 3.2 Gen 1 port 2
    Form Factor 2U Rackmount
    LED Indicators HDD, Status, 10 GbE, LAN, storage expansion port status
    Buttons Power, Reset
    Dimensions (HxWxD) 88 × 442.5 × 530.5 mm
    Weight (Net) 15.34 kg
    Weight (Gross) 21.25 kg
    Operating Temperature 0 - 40 °C (32°F - 104°F)
    Storage Temperature -20 - 70°C (-4°F - 158°F)
    Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
    Power Supply Unit Redundant/ Hot Swap ATX Power Supply,Input:
    47-63 Hz
    100-127V~/ 8A
    200-240V/ 4A
    Output: 450W
    Power Consumption: Operating Mode, Typical 229.53 W
    Fan 4 x 60mm
    System Warning Buzzer
    Standard Warranty 5
    Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
    Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
    Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
    QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
    The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
    Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
    Designs and specifications are subject to change without notice.

  2. TES-1885U-D1521-16GR (Legacy)
    CPU Intel® Xeon® D-1521 4-core 2.4 GHz processor, Max turbo to 2.7 GHz.
    CPU Architecture 64-bit x86
    Floating Point Unit
    Encryption Engine (AES-NI)
    System Memory 16 GB RDIMM DDR4 ECC (2 x 8 GB)
    Maximum Memory UDIMM: 64 GB (4 x 16 GB)
    RDIMM: 128GB (4 x 32 GB)
    Memory Slot 4 x RDIMM DDR4
    32 GB (above) RAM is required for QES operating system.
    You can only use one type of dual in-line memory module (DIMM) at a time. Do not use registered DIMM (RDIMM) with unbuffer DIMM (UDIMM) memory.
    Flash Memory 4GB (DOM for dual OS)
    Drive Bay Front: 12 x 3.5-inch
    Rear: 6 x 2.5-inch
    Drive Compatibility 3.5-inch bays:
    3.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA solid state drives

    2.5-inch bays:
    2.5-inch SATA solid state drives
    Hot-swappable
    SSD Cache Acceleration Support
    GPU pass-through
    Gigabit Ethernet Port (RJ45) 4
    10 Gigabit Ethernet Port 2 x 10GbE SFP+
    Wake on LAN (WOL)
    Jumbo Frame
    PCIe Slot 4
    Slot 1: PCIe Gen 3 x8
    Slot 2: PCIe Gen 2 x4
    Slot 3: PCIe Gen 3 x4
    Slot 4: PCIe Gen 3 x4 or PCIe Gen 3 x8
    Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3.
    USB 3.2 Gen 1 port 2
    Form Factor 2U Rackmount
    LED Indicators HDD, Status, 10 GbE, LAN, storage expansion port status
    Buttons Power, Reset
    Dimensions (HxWxD) 88 × 442.5 × 530.5 mm
    Weight (Net) 15.34 kg
    Weight (Gross) 21.25 kg
    Operating Temperature 0 - 40 °C (32°F - 104°F)
    Storage Temperature -20 - 70°C (-4°F - 158°F)
    Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
    Power Supply Unit Redundant/ Hot Swap ATX Power Supply,Input:
    47-63 Hz
    100-127V~/ 8A
    200-240V/ 4A
    Output: 450W
    Power Consumption: Operating Mode, Typical 229.53 W
    Fan 4 x 60mm
    System Warning Buzzer
    Standard Warranty 5
    Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
    Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
    Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
    QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
    The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
    Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
    Designs and specifications are subject to change without notice.

  3. TES-1885U-D1531-32G (Legacy)
    CPU Intel® Xeon® D-1531 6-core 2.2 GHz processor, Max turbo to 2.7 GHz.
    CPU Architecture 64-bit x86
    Floating Point Unit
    Encryption Engine (AES-NI)
    System Memory 32 GB UDIMM DDR4( 2 x 16 GB)
    Maximum Memory UDIMM: 64 GB (4 x 16 GB)
    RDIMM: 128GB (4 x 32 GB)
    Memory Slot 4 x UDIMM DDR4
    32 GB (above) RAM is required for QES operating system.
    You can only use one type of dual in-line memory module (DIMM) at a time. Do not use registered DIMM (RDIMM) with unbuffer DIMM (UDIMM) memory.
    Flash Memory 4GB (DOM for dual OS)
    Drive Bay Front: 12 x 3.5-inch
    Rear: 6 x 2.5-inch
    Drive Compatibility 3.5-inch bays:
    3.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA solid state drives

    2.5-inch bays:
    2.5-inch SATA solid state drives
    Hot-swappable
    SSD Cache Acceleration Support
    GPU pass-through
    Gigabit Ethernet Port (RJ45) 4
    10 Gigabit Ethernet Port 2 x 10GbE SFP+
    Wake on LAN (WOL)
    Jumbo Frame
    PCIe Slot 4
    Slot 1: PCIe Gen 3 x8
    Slot 2: PCIe Gen 2 x4
    Slot 3: PCIe Gen 3 x4
    Slot 4: PCIe Gen 3 x4 or PCIe Gen 3 x8
    Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3.
    USB 3.2 Gen 1 port 2
    Form Factor 2U Rackmount
    LED Indicators HDD, Status, 10 GbE, LAN, storage expansion port status
    Buttons Power, Reset
    Dimensions (HxWxD) 88 × 442.5 × 530.5 mm
    Weight (Net) 15.34 kg
    Weight (Gross) 21.25 kg
    Operating Temperature 0 - 40 °C (32°F - 104°F)
    Storage Temperature -20 - 70°C (-4°F - 158°F)
    Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
    Power Supply Unit Redundant/ Hot Swap ATX Power Supply,Input:
    47-63 Hz
    100-127V~/ 8A
    200-240V/ 4A
    Output: 450W
    Power Consumption: Operating Mode, Typical 229.53 W
    Fan 4 x 60mm
    System Warning Buzzer
    Standard Warranty 5
    Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
    Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
    Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
    QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
    The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
    Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
    Designs and specifications are subject to change without notice.

  4. TES-1885U-D1531-32GR (Legacy)
    CPU Intel® Xeon® D-1531 6-core 2.2 GHz processor, Max turbo to 2.7 GHz.
    CPU Architecture 64-bit x86
    Floating Point Unit
    Encryption Engine (AES-NI)
    System Memory 32 GB RDIMM DDR4 ECC (4 x 8 GB)
    Maximum Memory UDIMM: 64 GB (4 x 16 GB)
    RDIMM: 128GB (4 x 32 GB)
    Memory Slot 4 x RDIMM DDR4
    32 GB (above) RAM is required for QES operating system.
    You can only use one type of dual in-line memory module (DIMM) at a time. Do not use registered DIMM (RDIMM) with unbuffer DIMM (UDIMM) memory.
    Flash Memory 4GB (DOM for dual OS)
    Drive Bay Front: 12 x 3.5-inch
    Rear: 6 x 2.5-inch
    Drive Compatibility 3.5-inch bays:
    3.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA solid state drives

    2.5-inch bays:
    2.5-inch SATA solid state drives
    Hot-swappable
    SSD Cache Acceleration Support
    GPU pass-through
    Gigabit Ethernet Port (RJ45) 4
    10 Gigabit Ethernet Port 2 x 10GbE SFP+
    Wake on LAN (WOL)
    Jumbo Frame
    PCIe Slot 4
    Slot 1: PCIe Gen 3 x8
    Slot 2: PCIe Gen 2 x4
    Slot 3: PCIe Gen 3 x4
    Slot 4: PCIe Gen 3 x4 or PCIe Gen 3 x8
    Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3.
    USB 3.2 Gen 1 port 2
    Form Factor 2U Rackmount
    LED Indicators HDD, Status, 10 GbE, LAN, storage expansion port status
    Buttons Power, Reset
    Dimensions (HxWxD) 88 × 442.5 × 530.5 mm
    Weight (Net) 15.34 kg
    Weight (Gross) 21.25 kg
    Operating Temperature 0 - 40 °C (32°F - 104°F)
    Storage Temperature -20 - 70°C (-4°F - 158°F)
    Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
    Power Supply Unit Redundant/ Hot Swap ATX Power Supply,Input:
    47-63 Hz
    100-127V~/ 8A
    200-240V/ 4A
    Output: 450W
    Power Consumption: Operating Mode, Typical 229.53 W
    Fan 4 x 60mm
    System Warning Buzzer
    Standard Warranty 5
    Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
    Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
    Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
    QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
    The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
    Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
    Designs and specifications are subject to change without notice.

  5. TES-1885U-D1531-128GR (Legacy)
    CPU Intel® Xeon® D-1531 6-core 2.2 GHz processor, Max turbo to 2.7 GHz.
    CPU Architecture 64-bit x86
    Floating Point Unit
    Encryption Engine (AES-NI)
    System Memory 128 GB RDIMM DDR4 ECC (4 x 32 GB)
    Maximum Memory UDIMM: 64 GB (4 x 16 GB)
    RDIMM: 128GB (4 x 32 GB)
    Memory Slot 4 x RDIMM DDR4
    32 GB (above) RAM is required for QES operating system.
    You can only use one type of dual in-line memory module (DIMM) at a time. Do not use registered DIMM (RDIMM) with unbuffer DIMM (UDIMM) memory.
    Flash Memory 4GB (DOM for dual OS)
    Drive Bay Front: 12 x 3.5-inch
    Rear: 6 x 2.5-inch
    Drive Compatibility 3.5-inch bays:
    3.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA hard disk drives
    2.5-inch SAS/SATA solid state drives

    2.5-inch bays:
    2.5-inch SATA solid state drives
    Hot-swappable
    SSD Cache Acceleration Support
    GPU pass-through
    Gigabit Ethernet Port (RJ45) 4
    10 Gigabit Ethernet Port 2 x 10GbE SFP+
    Wake on LAN (WOL)
    Jumbo Frame
    PCIe Slot 4
    Slot 1: PCIe Gen 3 x8
    Slot 2: PCIe Gen 2 x4
    Slot 3: PCIe Gen 3 x4
    Slot 4: PCIe Gen 3 x4 or PCIe Gen 3 x8
    Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3.
    USB 3.2 Gen 1 port 2
    Form Factor 2U Rackmount
    LED Indicators HDD, Status, 10 GbE, LAN, storage expansion port status
    Buttons Power, Reset
    Dimensions (HxWxD) 88 × 442.5 × 530.5 mm
    Weight (Net) 15.34 kg
    Weight (Gross) 21.25 kg
    Operating Temperature 0 - 40 °C (32°F - 104°F)
    Storage Temperature -20 - 70°C (-4°F - 158°F)
    Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
    Power Supply Unit Redundant/ Hot Swap ATX Power Supply,Input:
    47-63 Hz
    100-127V~/ 8A
    200-240V/ 4A
    Output: 450W
    Power Consumption: Operating Mode, Typical 229.53 W
    Fan 4 x 60mm
    System Warning Buzzer
    Standard Warranty 5
    Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
    Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
    Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
    QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
    The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
    Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
    Designs and specifications are subject to change without notice.

QES OS

High Availability
  1. Automatically hardware error detection and failover
  2. Automatically failback when hardware recovered
  3. Data port network failover
  4. Near zero downtime high availability
  5. MPIO for iSCSI high availability
  6. Link aggregation for network load balance and fault tolerance
Networking
  1. TCP/IP (IPv4 & IPv6)
  2. 10 Gigabit NICs with jumbo frame (LACP, Load Balance, Failover, Round Robin)
  3. Service binding based on network interfaces
  4. Protocols: CIFS/SMB2/SMB3, NFS v3/NFS v4, FTP, FTPS, TFTP, HTTP, HTTPS, SSH, iSCSI, SNMP, SMTP, and SMSC
  5. Bonjour Discovery
Supported Client OS
  1. Windows 7 (32/64-bit), Windows 8 (32/64-bit), Windows 10 (32/64-bit), Windows Server 2008 R2/2012/2012R2/2016
  2. Apple Mac OS X
  3. Linux & UNIX
File Server
  1. Shared folder for CIFS/SMB, NFS and FTP
  2. File sharing across Windows, Mac, and Linux/UNIX
  3. Windows ACL
  4. Advanced Folder Permissions
Power Management
  1. Wake on LAN
  2. Automatic power on after power recovery
  3. Network UPS support with SNMP management
Security
  1. Network access protection with auto-blocking: SSH, HTTP(S), FTP, CIFS/SMB
  2. CIFS/SMB host access control for shared folders
  3. FIPS 140-2 validated AES 256-bit volume-based and shared folder data encryption
  4. Importable SSL certificates
  5. Instant alert via Email, SMS, beep
Supported Browsers
  1. Microsoft Internet Explorer
  2. Mozilla Firefox
  3. Apple Safari
  4. Google Chrome
FTP Server
  1. FTP over SSL/TLS (Explicit)
  2. FXP support
  3. Passive ftp port range control
Access Right Management
  1. Batch users creation
  2. Import/Export users
  3. User quota management
  4. Local user access control for CIFS/SMB and FTP
Storage Management
  1. Storage space utilization monitoring
  2. Storage pool with RAID 0, 1, 5, 6, 10, 50, 60, RAID TP, triple Mirror
  3. Global hot spare
  4. SSD read cache
  5. NVRAM write cache (BBU-protected)
  6. Scheduled Backup Battery Unit (BBU) learning
  7. Share folder/LUN with thin provisioning
  8. Instantly LUN provisioning
  9. Enable quota on share folder
  10. Reclaim unused storage space
  11. Supports snapshots
    • Shared Folder/LUN with snapshot protection
    • Snapshot manager
    • Snapshot clone
    • Snapshot agent for Windows VSS and VMware
  12. Shared Folder/LUN with encryption protection
  13. WORM (Write Once Read Many) for Shared Folder
  14. Online LUN expansion
  15. Online Share Folder quota expansion
  16. Online storage pool expansion
  17. Hard drive S.M.A.R.T.
  18. SMART predict data migration
  19. Time-Limited Error Recovery (TLER)
  20. Storage expansion via QNAP EJ-1600 series expansion units*
  21. JBOD ID Reinitialized
  22. RAID recovery
  23. Checksum for end-to-end data integrity
  24. Silence error detection and self-healing
  25. Pool scrub for data verification
Multilingual Support
  1. Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
High Efficiency
  1. Inline deduplication for Shared Folder/LUN
  2. Iinline compression for Shared Folder/LUN
Domain Authentication Integration
  1. Microsoft Active Directory support
  2. LDAP client
  3. Domain users login via CIFS/SMB, NFS, and FTP
Backup Management
  1. Data backup from a remote Rsync server or NAS server
  2. Block Level Snapshot replication (Snapsync)
File System
  1. ZFS
Virtualization
  1. VMware Ready
  2. vSphere Client plug-in
  3. VMware VAAI
    • Thin Provisioning with Space Reclamation
    • HW Assisted Locking
    • Full Copy
    • Block Zero
  4. VMware NAS VAAI
    • Space Reserve
    • Native Snapshot for Linked Clones
    • File Cloning
    • Extended Stats
  5. Certified for Windows 2012 R2/Windows 2016
  6. Support Microsoft ODX (Offload Data Transfer)
  7. Citrix Ready
Administration
  1. Multi-window, multi-tasking based system management
  2. Movable Icons and personalized desktop
  3. Smart toolbar and dashboard for neat system status display
  4. Smart fan Control
  5. SNMP (V1/V2 & V3)
  6. Resource monitor
  7. Network recycle bin for file deletion via Filestation,
  8. FTP and Samba
  9. Smart file filter
  10. Comprehensive logs (events & connection)
  11. Syslog client management
  12. System settings backup and restore
  13. Restore to factory default
  14. Command Line Interface (CLI)
Storage for Backup
  1. Veeam Ready



QTS OS

Operating System
QTS 4.2 (embedded Linux)
Power Management
  1. Wake on LAN
  2. Internal hard drive standby mode
  3. Scheduled power on/off
  4. Automatic power on after power recovery
  5. USB and network UPS support with SNMP management
  6. System sleep mode (S3)3
Supported Client OS
  1. Apple Mac OS 10.7 or later
  2. Linux and UNIX
  3. Microsoft Windows 7, 8, and 10
  4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016
Access Right Management
  1. Batch users creation
  2. Import/Export users
  3. User quota management
  4. Local user access control for CIFS, AFP, FTP, and WebDAV
  5. Application access control for Photo Station, Music Station, Video Station, and File Station
  6. Subfolder permissions support for CIFS/SMB, AFP, FTP, and File Station
Supported Browsers
  1. Microsoft Internet Explorer 10+
  2. Google Chrome
  3. Apple Safari 7+
  4. Mozilla Firefox
Domain Authentication Integration
  1. Microsoft Active Directory (AD) & Domain Controller support
  2. LDAP server, LDAP client
  3. Domain users login via CIFS/SMB, AFP, FTP, and File Station
Multilingual Support
  1. Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
myQNAPcloud Service
  1. Private cloud storage and sharing
  2. Free host name registration (DDNS)
  3. Optional myQNAPcloud SSL certificates (DDNS)
  4. Auto router configuration (via UPnP)
  5. Web-based file manager with HTTPS 2048-bit encryption
  6. myQNAPcloud Link for remote access without any complicated router setup
  7. myQNAPcloud connect for easy VPN connection (Windows VPN utility)
File System
  1. Internal Hard Drive: EXT4
  2. External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Qsync
  1. Sync files across multiple devices with SSL secure connection
  2. Selective synchronization for only syncing specific folders
  3. Use team folders as a file center for greater team collaboration (maximum sync tasks: x86: 32, ARM: 5)
  4. Shares files by links via e-mail
  5. Policy settings for conflicting files and file type filter support
  6. Version control: up to 64 versions.
  7. Unified privilege management
  8. Unified configuration management
  9. Supports central configuration mode
  10. Supports remote erase/restore
  11. Supports shared folders sync
  12. Supports Windows & Mac OS
Networking
  1. TCP/IP (IPv4 & IPv6: Dual Stack)1
  2. Quad Gigabit NICs with jumbo frame (failover, multi-IP settings, port trunking/NIC teaming)
  3. Service binding based on network interfaces
  4. Squid Proxy server
  5. Proxy client
  6. DHCP client, DHCP server
  7. Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
  8. UPnP & Bonjour Discovery
  9. USB Wi-Fi Adapter Support**
    ** 802.11ac support may vary by model.
  10. Network & Virtual Switch
Web Administration
  1. Multi-window, multi-tasking based system management
  2. Smart toolbar and dashboard for neat system status display
  3. Dynamic DNS (DDNS)
  4. SNMP (v2 & v3)
  5. Resource monitor
  6. Network recycle bin for file deletion via CIFS/SMB, AFP, and File Station
    • Automatic Cleanup
    • File Type Filter
  7. Comprehensive logs (events & connection)
  8. Syslog client/server
  9. System settings backup and restore
  10. Mobile app: Qmanager for remote system monitoring & management
Security
  1. Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
  2. CIFS host access control for shared folders
  3. FIPS 140-2 validated AES 256-bit volume-based and shared folder data encryption2
  4. AES 256-bit external drive encryption2
  5. Importable SSL certificates
  6. Instant alerts via email, SMS, beep, push service, and LCD panel3
  7. 2-step verification
File Server
  1. File sharing across Windows, Mac, and Linux/UNIX
  2. Microsoft networking
  3. Windows ACL
  4. Advanced folder permissions for CIFS/SMB, AFP, FTP
  5. Shared folder aggregation (CIFS/SMB)
Storage Management
  1. Storage Space Utilization monitoring
  2. QNAP flexible Volume/LUN with thin provisioning and space reclaim3
  3. Disk volume types: RAID 0, 1, 5, 6, 10, + hot spare, JBOD single
  4. Supports storage pools3
  5. Supports Qtier™ Technology (Auto Tiering, 8GB System RAM and SSD drives are required)3
  6. Supports snapshots (4GB System RAM required)3
    • Supports Volume/LUN snapshot
    • Snapshot manager
    • Snapshot clone
    • Snapshot vault
    • Snapshot replica
    • Snapshot agent for Microsoft Windows and VMware vSphere
  7. Online volume expansion
  8. Online storage pool expansion
  9. Online RAID capacity expansion and online RAID level migration
  10. SMART data migration
  11. Storage expansion via QNAP TX-500P/UX-800P expansion units3
  12. JBOD enclosure roaming
  13. SSD read-only/read-write cache
  14. Bad block scan and hard drive S.M.A.R.T.
  15. Bad block recovery & RAID recovery
  16. Bitmap support
FTP Server
  1. FTP over SSL/TLS (Explicit)
  2. FXP support
Powerful All-in-one server
File Station
  1. Supports mounting cloud drives (such as Google Drive, Dropbox, Microsoft OneDrive, Amazon Cloud Drive, Yandex Disk and Box).
  2. Supports mounting remote shared folders through FTP, WebDAV or Microsoft networking (SMB/CIFS)
  3. Supports opening documents via Office Online, Google Docs or Chrome Extension (Edit Office files in Google Docs, Sheets, and Slides)
  4. Supports ISO Mounting (Up to 256 ISO Files)
  5. Supports sharing download links and upload links
  6. Drag-n-drop Files via Chrome and Firefox Browsers
  7. Photo, music, and video preview and playback with hardware accelerated transcoding3
  8. File Compression (ZIP or 7z)
  9. Creation of and sending download links for sharing public files with expiration date and password protection
  10. Supports displaying subtitles (*.SRT, UTF-8 format)
    • Video seeking support for video playback during on-the-fly transcoding3
    • Supports slideshow playback in media viewer
  11. Mobile App: Qfile for file browsing and management
Linux Station
  1. Support install the Ubuntu OS via Linux Station. Use your NAS as a Ubuntu PC using the NAS HDMI™ output.
  2. Download and use a variety of applications from the Ubuntu Software Center.
  3. Supports remote desktop to monitor and access Ubuntu remotely.
  4. An open source software platform for developers.
Note: The NAS requires at least 4GB RAM and Container Station must be installed.
Transcode Management
  1. Transcode video files to 240p, 360p, 480p, 720p and 1080p resolution
  2. Automatic video transcoding for watched folders
  3. Hardware accelerated transcoding support3
  4. Embed subtitles into videos for background transcoding
Virtualization Station3
  1. Supports Virtual Machine (VM) creation to run operating systems such as Windows, Linux, Unix and Android
  2. Supports VM import and export
  3. Supports VM cloning & snapshots
  4. Supports VM backup and restore
  5. VM console can be displayed via HDMI™ output - QVM
  6. HTML5-based shared remote console
  7. Supports three different networking modes: Isolated, External-only and Bridged
  8. Supports GPU pass-through via the discrete card
Backup Station
  1. Remote replication server (over rsync)
  2. Real-time remote replication (RTRR) to another QNAP NAS, FTP or CIFS/SMB server
  3. Works as both RTRR server & client with bandwidth control
  4. Real-time & scheduled backup
  5. Backup versioning for RTRR
  6. Snapshot support for RTRR/Rsync
  7. Encryption, compression, file filter, and transfer rate limitation
  8. Desktop backup with QNAP NetBak Replicator for Windows®
  9. Apple Time Machine backup support
  10. Data backup to multiple external storage devices
  11. Third party backup software support: Veeam backup & replication, Acronis True Image, Arcserve backup, emc retrospect, Symantec Backup Exec, etc.
Container Station
  1. Supports LXC and Docker
  2. Download applications from the built-in Docker Hub Registry
  3. Supports one-click installation, container export/import & console mode
  4. Supports two network modes (NAT and host)
  5. Supports auto-start containers
  6. Supports downloading Docker certificates
  7. Supports adding private registries
  8. Added an application repository for users to switch to any repository on GitHub.com.
Cloud Drive Sync
  1. Multiple cloud account management like Google Drive, Dropbox, OneDrive, and hubiC
  2. Supports multiple cloud accounts
  3. Manual, scheduled, periodic and continuous sync
  4. Flexible file filtering using type, date, and size
  5. SSL transfer encryption
  6. Dashboard and job statistics
  7. Configurable network error recovery options
  8. Extensive job activity logging for tracing history of status and statistics
  9. Concurrent job execution and multi-threaded data transfer
  10. Per-account bandwidth throttling
Web Server
  1. HTTP/HTTPS Connections
  2. Supports WebDAV Connection
  3. Supports Virtual Host (Max: 32)
  4. Importable SSL Certificate
Cloud Backup Station
  1. S3 Plus (including Amazon S3)
  2. Amazon Glacier
  3. Google Cloud Storage
  4. WebDAV-based cloud storage
  5. Microsoft Azure
  6. OpenStack Swift
Qsirch
  1. Supports full-text search
  2. Supports near real-time search
  3. Bar chart to show data distribution
  4. Supports previews for photos, music, videos, Gmail, PDF .etc
  5. Show search results using thumbnails or a list
  6. Supports search Chrome extension
Print Server
  1. Max number of printers: 3
  2. Supports Internet Printing Protocol
  3. Print job display and management
  4. IP-based and domain name-based privilege control
iSCSI (IP SAN)
  1. iSCSI target with multi-LUNs per target (Up to 256 targets/LUNs combined)
  2. Supports LUN mapping & masking
  3. Online LUN capacity expansion
  4. Support for SPC-3 persistent reservation
  5. Supports MPIO & MC/S
  6. iSCSI LUN backup, one-time snapshot, and restoration
  7. iSCSI connection and management by QNAP Windows Qfinder
  8. Virtual disk drive (via iSCSI initiator)
  9. Stack chaining master
  10. Max No. of virtual disk drives: 8
Photo Station
  1. Show photos by thumbnails, list, timeline, or folder view
  2. Supports virtual/smart albums
  3. Validity control for sharing albums
  4. Tag photos with text, colors, and ratings
  5. Slideshows with background music and different transition effects
  6. Geotag photos and display them on Google maps
  7. Supports uploading photos/videos to Picasa, Flickr, Weibo, YouTube
  8. Supports face detection (with the Photo Station Extension)
  9. Supports PDF to image conversion (with the Photo Station Extension)
  10. Supports Facebook friends login
  11. Backup/Restore album configuration
Surveillance Station
  1. Supports over 3,000 IP cameras
  2. Includes 8 free camera licenses, up to 80 camera channels by purchasing additional licenses3
  3. Instant playback to check recent events
  4. Visual aid by e-map
  5. Playback and speed control using the shuttle bar
  6. Video preview on playback timeline
  7. Intelligent video analytics (IVA) for advanced video searching
  8. Surveillance client for Mac
  9. Mobile surveillance app: Vmobile (iOS and Android)
  10. Mobile recording app: Vcam (iOS and Android)
Music Station
  1. Play or share music via web browser
  2. Supports streaming music to multiple devices.
  3. Supports changing album covers via Google search or by uploading photos.
  4. Internet radio (MP3)
  5. Up to 8 music alarms
  6. Mobile app: Qmusic for music streaming and management
VPN Server
  1. Secure remote access: PPTP、L2TP/IPsec & OpenVPN VPN services
  2. Max number of clients: 300
VPN Client
  1. Supported VPN protocols: PPTP and OpenVPN services
  2. PPTP Authentication: PAP, CHAP, MS-CHAP, MS-CHAPv2
  3. PPTP Encryption: None, AES 40/128 bit, AES 256 bit
  4. OpenVPN Encryption: None, AES 40/128 bit, AES 256 bit
  5. Transmission package monitor
  6. OpenVPN port control
  7. OpenVPN link compression
Video Station
  1. Show photos by thumbnails, list, timeline, or folder view
  2. Supports virtual/smart collections
  3. Tag videos with text, color, and ratings
  4. Share video links to social websites or through email
  5. Display movie information and posters from Internet sources or user-uploaded files
  6. Supports displaying subtitles (*.SRT,*.ASS, *.SSA)
  7. Supports online searching and downloading of subtitles as well as importing subtitle files
  8. Supports adjusting the display style of subtitles
  9. Supports Facebook friends login
  10. Supports multi-zone video display
  11. Video seeking support for video playback during on-the-fly transcoding3
  12. Mobile app: Qvideo for online video browsing and management
DLNA Server
  1. Supports DLNA/UPnP TVs and players such as PlayStation 4 and Xbox One
  2. Support CUE indexing file for APE, FLAC audio format.
  3. Video and Audio On-the-fly Transcoding3
Chromecast
  1. Streams videos, photos and music from NAS to Apple TV via Qmedia or Chromecast via File Station, Music Station, Photo Station, Video Station or mobile app (Qfile, Qmusic, Qphoto or Qvideo).

    Note: The Media Streaming add-on app must be installed from the QTS App Center.
Q'center (NAS CMS)
  1. Multiple NAS monitoring
  2. Utilization history reports
  3. Unified configuration management
  4. Visual display reports
  5. Monitor NAS behind NAT routers with Q’center Assistant
  6. Virtual appliances supported with Microsoft Hyper-V and VMware ESXi
Download Station
  1. PC-less BT, FTP/FTPS, and HTTP/HTTPS, Thunder, FlashGet and qqdl download (up to 500 Tasks)
  2. BT download with search, Magnet Link and PT support
  3. Scheduled download and bandwidth control
  4. RSS subscription and download (broadcatching)
  5. Proxy support for BT download
  6. Mobile app: Qget for downloads browsing and management
OceanKTV
  1. Use the NAS as a karaoke machine.
  2. Display songs by artists, languages, and favorites.
  3. Enhance the experience with effects such as tuning echo, key, or applause
  4. Control the playlist with a mobile app.
  5. Supports keyboard and remote control (RM-RF001/ RM-IR002).
Note: Microphone not included.
Notes Station
  1. Direct and quick backup from Evernote with re-editing availability
  2. Supports Google Calendar
  3. Import/Export PDF and .epub file
  4. RSS live feed and auto update
  5. Online quick preview of multimedia attachments
  6. Notes encrypt/decrypt
  7. Smart snapshot for version control
  8. Full site backup for admin user
Qfinder Pro with Storage Plug & Connect
  1. Creating and mapping shared folders by QNAP Windows Qfinder Pro
  2. Creation of and connection to iSCSI target/LUN
HD (HybridDesk) Station 3.13
  1. Playback videos, music, photos on TV with Kodi via HDMI™
  2. Watch various online content such as YouTube, Flickr, Picasa, Shoutcast, etc.
  3. Web browsers (Chrome, Firefox)
  4. Supports international keyboards, input and mouse
  5. Supports QNAP Qremote app and the official Kodi remote app
  6. Supports user login permissions
  7. A variety of applications are available including Skype, Plex Home Theater, and more
Note: The playback and quality of some video files may be affected by the system’s CPU and GPU decoding abilities.
App Center
  1. Over 100 official and community software add-ons

1 Not all IPv6 services are supported.
2 Data encryption functions may be unavailable in accordance with the legislative restrictions of some countries.
3 This feature may vary by model.
4 DRM-protected content is not supported.

Designs and specifications are subject to change without notice.

TES-1885U Ethernet cable x 4 Power cord x 2
Flat head screws (for 3.5” HDD) Flat head screws (For 2.5” HDD) Quick Installation Guide

A03 series (Chassis) rail kit, max. load 57kg: RAIL-A03-57

Optional Accessories

  1. QM2-2P-344
    QM2-2P-344 (EOL)
    QM2-2P-344A
    QM2-2P-344A
    QM2-2P-384
    QM2-2P-384 (EOL)
    QM2-2P-384A
    QM2-2P-384A
    QM2-2P10G1TB
    QM2-2P10G1TB
    QM2-4P-384
    QM2-4P-384
    QM2-4S-240
    QM2-4S-240 (EOL)
    QDA-A2AR
    QDA-A2AR
    QDA-A2MAR
    QDA-A2MAR
    LAN-10G2SF-MLX
    LAN-10G2SF-MLX (EOL)
    LAN-10G2T-X550
    LAN-10G2T-X550 (EOL)
    LAN-40G2SF-MLX
    LAN-40G2SF-MLX (EOL)
    QXG-10G2T
    QXG-10G2T
    QXG-10G2T-107
    QXG-10G2T-107 (EOL)
    QXG-10G2TB
    QXG-10G2TB (EOL)
    QXG-25G2SF-CX6
    QXG-25G2SF-CX6
    QXG-2G1T-I225
    QXG-2G1T-I225
    QXG-2G2T-I225
    QXG-2G2T-I225
    QXG-5G1T-111C
    QXG-5G1T-111C
    QXG-5G2T-111C
    QXG-5G2T-111C
    QXG-5G4T-111C
    QXG-5G4T-111C
    PWR-PSU-770W-DT01
    PWR-PSU-770W-DT01 (EOL)
    QNA-UC5G1T
    SCR-HDD25A-96
    SCR-HDD25A-96
    SP-A02-6CM4-FAN-MODULE
    SP-A02-6CM4-FAN-MODULE (EOL)
    SP-A02-8CM4A-FAN-MODULE
    SP-A02-8CM4A-FAN-MODULE (EOL)
    SP-A02-8CM4B-FAN-MODULE
    SP-A02-8CM4B-FAN-MODULE (EOL)
    SP-X79U-TRAY
    SP-X79U-TRAY
    TRAY-25-NK-BLK02
    TRAY-25-NK-BLK02
    RAIL-A03-57
    RAIL-A03-57
    QXP-10G2U3A
    QXP-10G2U3A
    QXP-1620S-B3616W
    QXP-1620S-B3616W
    QXP-16G2FC
    QXP-16G2FC
    QXP-32G2FC
    QXP-32G2FC
    QXP-820S-B3408
    QXP-820S-B3408
    USB-U31A2P01
    USB-U31A2P01 (EOL)
    TRX-16GFCSFP-SR
    TRX-16GFCSFP-SR
    TRX-32GFCSFP-SR
    TRX-32GFCSFP-SR
    CAB-DAC15M-SFP28
    CAB-DAC15M-SFP28
    CAB-DAC15M-SFPP
    CAB-DAC15M-SFPP
    CAB-DAC30M-SFP28
    CAB-DAC30M-SFP28
    CAB-NIC40G30M-QSFP
    CAB-NIC40G30M-QSFP
    CAB-SAS05M-8644
    CAB-SAS05M-8644
    CAB-SAS05M-8644-8088
    CAB-SAS05M-8644-8088
    CAB-SAS10M-8644
    CAB-SAS10M-8644
    CAB-SAS10M-8644-8088
    CAB-SAS10M-8644-8088
    CAB-SAS20M-8644
    CAB-SAS20M-8644
    CAB-SAS20M-8644-8088
    CAB-SAS20M-8644-8088
    CAB-SAS30M-8644
    CAB-SAS30M-8644
    CAB-SAS30M-8644-8088
    CAB-SAS30M-8644-8088
    RAM-16GDR4-LD-2133
    RAM-16GDR4-LD-2133
    RAM-8GDR4-LD-2133
    RAM-8GDR4-LD-2133
    RAM-16GDR4ECT0-RD-2400
    RAM-16GDR4ECT0-RD-2400
    RAM-32GDR4ECK0-RD-2666
    RAM-32GDR4ECK0-RD-2666 (EOL)
    RAM-32GDR4ECT0-RD-2133
    RAM-32GDR4ECT0-RD-2133 (EOL)
    RAM-8GDR4-RD-2400
    RAM-8GDR4-RD-2400
    RAM-8GDR4ECT0-RD-2400
    RAM-8GDR4ECT0-RD-2400
Bundled accessories delivered together with the product such as expansion cards, power adapter, and accessories are covered with one-year warranty.

Choose specification

      Show more Less

      Choose Your Country or Region

      open menu
      back to top
