QXG-10G2T-X710 Specification

  1. Dual-port, 5-speed 10 GbE network expansion card

    Méretek (H x Sz x M) 111,58 mm length × 1-slot width × Low-profile (The dimension is based on PCBA size × not including the bracket) mm
    Vezérlő Intel Ethernet Controller X710
    Portok száma 2 x NBASE-T (RJ45)
    Csatlakozó NBASE-T (RJ45)
    PCIe és sávok PCIe 3.0 x4
    Átviteli sebességek 10Gbps/5Gbps/2.5Gbps/1Gbps/100Mbps
    IEEE szabványok IEEE 802.1Q
    IEEE 802.3x
    IEEE 802.1p
    IEEE 802.3ad
    IEEE 802.3ae
    IEEE 1588
    IEEE 802.1as
    Rögzítőkeret Low-profile bracket pre-installed; full-height and specialized (for selected QNAP NAS) brackets are bundled
    SR-IOV támogatás
    NVGRE, VXLAN, Geneve támogatás
    1K be- és kimeneti QoS szintek On-chip QoS
    Hány virtuális funkció 128
    (64/port)
    Támogatott NAS operációs rendszerek QTS 4.4.3 or later (recommend an upgrade to the latest version); Windows 10 (1809 or later); Linux Stable Kernel 4.20/5.x; Windows Server 2019 (Driver required)
    Támogatott QNAP NAS Models with PCIe slot(s) (1 free slot required)
    Támogatja az Ubuntu kereskedelmi Linux disztribúcióit Ubuntu 18.04/20.04
    Windows támogatás Windows 8/10
    Support Windows Server Windows Server 2016/2019
    Port és kábel RJ-45; over CAT-6 class cable
    Package Contents 1 x Network card; 1 x QIG; 3 x Brackets
    Standard Warranty 3 years
    Note: QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
    Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
    Designs and specifications are subject to change without notice.
