QDA-UMP4 Specification
-
Use an M.2 PCIe NVMe SSD in a U.2 PCIe NVMe SSD drive bay for PC and NAS
Standard Warranty 2 years Supported Drives 1 x M.2 2280 PCIe 4.0 x4 NVMe SSD Host Interface U.2 (SFF-8639) PCIe 4.0 x4 Supported Operating Systems 1. QTS 4.4.1 (or later)
2. Windows: Windows 7, 8.1, 10, Windows Server 2012 R2
3. UbuntuDimensions (L x W x H) 100.4 × 69.85 × 15 mm Weight 0.1045 kg Note Consult your PC system provider if the PC operating system supports U.2 NVMe SSD. Architecture Diagram
Note: QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
QDA-UMP4
Pan Head Screw x2 (for M.2 SSD)
M.2 SSD Thermal Pads x3
Quick Installation Guide (QIG)
Bundled accessories delivered together with the product such as expansion cards, power adapter, and accessories are covered with one-year warranty.
