TS-831X Specification

TS-831X
規格
購買→
訂購料號 TS-831X-4G TS-831X-8G
處理器 AnnapurnaLabs, an Amazon company Alpine AL-314 Quad-core 1.7 GHz Cortex-A15 processor
(Newly upgraded from 1.4 GHz)
硬體加密引擎
 ✔
記憶體 4GB DDR3 (1 x 4GB) 8GB DDR3 (1 x 8GB)
最大可擴充記憶體 16GB
記憶體插槽數 2 x SODIMM DDR3
注意：對於使用二個 DIMM 配置，需要安裝相同速度、容量和晶片類型的一對 DDR3 記憶體
快閃記憶體 512MB
最大硬碟數量 8 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs
10GbE 網路埠 2 x 10 Gigabit SFP+ 網路埠
GbE 網路埠 2 x Gigabit RJ45 網路埠
USB 埠 3 x USB 3.2 Gen 1 埠 (正面：1, 背面：2)
PCIe 插槽 1 x PCIe Gen2 ( x2)
LED 指示燈 狀態、USB、硬碟 1-8
按鍵 電源/狀態、USB 單鍵備份、系統重置按鈕
安全設計 Kensington 安全鎖、系統維護埠
尺寸 185.2 (高) x 298.2 (寬) x 235 (深) mm
7.29 (高) x 11.74 (寬) x 9.25 (深) inch
重量 淨重：6.26 kg (13.80 lbs)
毛重：7.61 kg (16.78 lbs)
溫度 0-40˚C
相對溼度 5~95% RH 不凝結；濕球：27˚C
噪音(dB) 20.6 dB (A)
耗電量 硬碟休眠模式：19.47 W
運行中：46.36 W
(含 8 顆 1TB 硬碟)
電源 ATX 250W 電源供應器, 110-240V AC, 50-60Hz, 3.5A
風扇 2 x 12cm 靜音風扇 (12V DC)

注意：請僅使用 QNAP 記憶體模組來維持系統的效能與穩定性。若 NAS 裝置有多個記憶體模組，請使用相同規格的 QNAP 模組，並參考硬體使用手冊安裝相容的 QNAP 記憶體模組。
警告：使用不支援的模組可能會降低效能、造成錯誤，或使作業系統無法啟動。
QNAP 有權視供應商產品供貨情況，更換部分零件或配件。其相容性與穩定性皆經過相同嚴格的測試檢驗，請用戶放心使用。
HDMI、HDMI High-Definition Multimedia Interface、HDMI Logo 是 HDMI Licensing Administrator, Inc. 的商標或註冊商標。
產品圖僅供示意，實際產品可能有所不同。由於螢幕顯示誤差，產品實際顏色亦可能和網站所示有所不同。
威聯通科技得保留隨時修改的權利，恕不另行通知。
Operating System
QTS 4.2 (embedded Linux)
File System
  1. Internal Hard Drive: EXT4
  2. External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Power Management
  1. Wake on LAN
  2. Internal hard drive standby mode
  3. Scheduled power on/off
  4. Automatic power on after power recovery
  5. USB and network UPS support with SNMP management
Qsync
  1. Syncs files across multiple devices with SSL support
  2. Selective synchronization for only syncing specific folders
  3. Use team folders as a file center for greater team collaboration (maximum sync tasks:32)
  4. Shares files by links via e-mail
  5. Policy settings for conflicting files and file type filter support
  6. Version control: up to 64 versions.
  7. Incremental synchronization for HDD space saving
  8. Unified privilege management
  9. Unified configuration management
  10. Supports central configuration mode
  11. Supports remote erase / restore
  12. Supports shared folders sync
  13. Supports Windows & Mac OS
Supported Client OS
  1. Apple Mac OS 10.7 or later
  2. Linux and UNIX
  3. Microsoft Windows 7, 8, and 10
  4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016
Networking
  1. TCP/IP (IPv4 & IPv6: Dual Stack)*
  2. NICs with jumbo frame (failover, multi-IP settings, port trunking/NIC teaming)
  3. Service binding based on network interfaces
  4. Squid Proxy server
  5. Proxy client
  6. DHCP client, DHCP server
  7. Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
  8. UPnP & Bonjour Discovery
  9. USB Wi-Fi Adapter Support
*Not all services supports IPv6.
Access Right Management
  1. Batch user creation
  2. Import/Export users
  3. User quota management
  4. Local user access control for CIFS, AFP, FTP, and WebDAV
  5. Application access control for Photo Station, Music Station, Video Station, and File Station
  6. Subfolder permissions support for CIFS/SMB, AFP, FTP, and File Station
Web Administration
  1. Movable Icons and personalized desktop
  2. Smart toolbar and dashboard for neat system status display
  3. Smart fan Control
  4. Dynamic DNS (DDNS)
  5. SNMP
  6. Resource monitor
  7. Network recycle bin for file deletion via CIFS/SMB, AFP, and File Station
    - Automatic Cleanup
    - File Type Filter
  8. Comprehensive logs (events & connection)
  9. Syslog client/server
  10. System settings backup and restore
  11. Restore to factory default
  12. Mobile app: Qmanager for remote system monitoring & management
Supported Browsers
  1. Microsoft Internet Explorer 10+
  2. Mozilla Firefox 8+
  3. Apple Safari 4+
  4. Google Chrome
Security
  1. Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
  2. CIFS host access control for shared folders
  3. FIPS 140-2 validated AES 256-bit volume-based data encryption*
  4. AES 256-bit external drive encryption*
  5. Importable SSL certificates
  6. Instant alert via E-mail, SMS, beep,and push service
  7. 2-step verification
    -Data encryption functions may be unavailable in accordance with the legislative restrictions of some countries.
Domain Authentication Integration
  1. Microsoft Active Directory (AD) & Domain Controller support
  2. LDAP server, LDAP client
  3. Domain users login via CIFS/SMB, AFP, FTP, and File Station
File Server
  1. File sharing across Windows, Mac, and Linux/UNIX
  2. Windows ACL
  3. Advanced folder permissions for CIFS/SMB, AFP, FTP
  4. Shared folder aggregation (CIFS/SMB)
Multilingual Support
  1. Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
Storage Management
  1. QNAP flexible Volume/LUN with thin provisioning and space reclaim
  2. Volume types: RAID 0/1/5/6/10/50/60, + hot spare, single, JBOD
  3. Supports storage pools
  4. Supports snapshots
    • Supports Volume/LUN snapshot
    • Snapshot manager
    • Snapshot clone
    • Snapshot vault
    • Snapshot replica
    • Snapshot agent for Microsoft Windows and VMware vSphere
  5. Online volume expansion & storage pool expansion
  6. Online RAID capacity expansion and online RAID level migration
  7. SMART data migration
  8. Storage expansion via max 2 QNAP UX-500P/UX-800P expansion units
  9. JBOD enclosure roaming
  10. SSD read-only/read-write cache
  11. Bad block scan, recovery, and hard drive S.M.A.R.T.
  12. RAID recovery
  13. Bitmap support
myQNAPcloud Service
  1. Private cloud storage and sharing
  2. Free host name registration (DDNS)
  3. Supports myQNAPcloud SSL certificates (DDNS)
  4. Auto router configuration (via UPnP)
  5. Web-based file manager with HTTPS 2048-bit encryption
  6. myQNAPcloud Link for remote access without any complicated router setup
  7. myQNAPcloud connect for easy VPN connection (Windows VPN utility)

Powerful All-in-one server
FTP Server
  1. FTP over SSL/TLS (Explicit)
  2. FXP support
  3. Passive ftp port range control
Surveillance Station
  1. Supports over 3,000 IP cameras
  2. Includes 2 free camera licenses, up to 30 camera channels via additional license purchase
  3. Instant playback to check recent events
  4. Online editing to edit cameras during live view
  5. Visual aid by e-map
  6. Playback and speed control using the shuttle bar
  7. Video preview on playback timeline
  8. Intelligent video analytics (IVA) for advanced video searching
  9. Surveillance client for Mac
  10. Mobile surveillance app: Vmobile (iOS and Android)
  11. Mobile recording app: Vcam (iOS and Android)
AirPlay & Chromecast
  1. Streams videos, photos and music from NAS to Apple TV or Chromecast via File Station, Music Station, Photo Station, Video Station or mobile app (Qfile, Qmusic, Qphoto or Qvideo).
Note: Media Streaming add-on app from the App Center is required
Photo Station
  1. Show photos by thumbnails, list, timeline, or folder view
  2. Supports virtual/smart albums
  3. Validity control for sharing albums
  4. Tag photos with text, colors, and ratings
  5. Slideshows with background music and different transition effects
  6. Geotag photos and display them on Google maps
  7. Advanced search by tags, metadata, etc
  8. Supports uploading photos/videos to Picasa, Flickr, Weibo, YouTube
  9. Share slideshows links to social websites or by email
  10. Supports Facebook friends login
  11. Backup/Restore album configuration
File Station
  1. Supports mounting a Cloud Drive (such as Google Drive, Dropbox, Microsoft OneDrive, Amazon Drive, Yandex Disk and Box).
  2. Supports mounting remote shared folders through FTP, WebDAV or Microsoft networking (SMB/CIFS)
  3. Supports opening documents via Office Online, Google Docs or Chrome Extension (Edit Office files in Google Docs, Sheets, and Slides)
  4. Supports ISO Mounting (Up to 256 ISO Files)
  5. Supports thumbnail display of multimedia files
  6. Supports sharing download links and upload links
  7. Supports sharing to other NAS users
  8. Drag-n-drop Files via Chrome and Firefox Browsers
  9. Photo, music, and video preview and playback
  10. File Compression (ZIP or 7z)
  11. Supports displaying subtitles (*.SRT, UTF-8 format)
  12. Supports slideshow playback in media viewer
  13. Mobile App: Qfile for file browsing and management
VPN Server
  1. Secure remote access: PPTP、L2TP/IPsec & OpenVPN VPN services
  2. Max number of clients: 300
Download Station
  1. PC-less BT, FTP/FTPS, and HTTP/HTTPS, Thunder, FlashGet and qqdl download (up to 500 Tasks)
  2. BT download with Magnet Link and PT support
  3. Scheduled download and bandwidth control
  4. RSS subscription and download (broadcatching)
  5. BT search
  6. Proxy support for BT download
  7. Mobile app: Qget for downloads browsing and management
Music Station
  1. Play or share music via web browser
  2. Automatic classification via Media Library
  3. Supported audio formats: AIFF, APE, FLAC, M4A, M4A Apple Lossless (ALAC), MP3, OggVorbis, WAV (PCM, LPCM),WMA, WMA PRO, WMA VBR*
  4. Supports streaming music to multiple devices
  5. Supports changing album covers via Google search or uploading photos
  6. Internet radio (MP3)
  7. Up to 8 music alarms
  8. Mobile app: Qmusic for music streaming and management
* DRM-protected content is not supported.
Backup Station
  1. Remote replication server (over rsync)
  2. Real-time remote replication (RTRR) to another QNAP NAS or FTP server
  3. Works as both RTRR server & client with bandwidth control
  4. Real-time & scheduled backup
  5. Backup versioning for RTRR
  6. Snapshot support for RTRR/Rsync
  7. Encryption, compression, file filter, and transfer rate limitation
  8. Encrypted replication between QNAP NAS servers
  9. Desktop backup with QNAP NetBak Replicator for Windows
  10. Apple Time Machine backup support
  11. Data backup to multiple external storage devices
  12. Synchronizes with cloud storage: Amazon S3, ElephantDrive, Dropbox, and Google Drive
  13. Third party backup software support: Acronis True Image, Arcserve backup, emc retrospect, Symantec Backup Exec, etc.
VPN Client
  1. Supported VPN protocols: PPTP & OpenVPN services
  2. PPTP Authentication: PAP, CHAP, MS-CHAP, MS-CHAPv2
  3. PPTP Encryption: None, AES 40/128 bit, AES 256 bit
  4. OpenVPN Encryption: None, AES 40/128 bit, AES 256 bit
  5. Transmission package monitor
  6. OpenVPN port control
  7. OpenVPN link compression
Storage Plug & Connect
  1. Creating and mapping shared folders by QNAP Windows Qfinder Pro
  2. Creation of and connection to iSCSI target/LUN
Container Station
  1. Supports LXC and Docker
  2. Supports CPU/Memory management
  3. Download applications from the built-in Docker Hub Registry
  4. Supports one-click installation, container export/import & console mode
  5. Supports mounting NAS shared folders and data-only containers
  6.  Supports auto port forwarding
  7. Supports auto-start containers
  8. Supports downloading Docker certificates
DLNA Server
  1. Supports DLNA/UPnP TVs and players such as PlayStation 4 and Xbox One
  2. Supported audio formats: AIFF, APE, DSD (DSF, DFF), FLAC, M4A, M4A Apple Lossless (ALAC), MP3, OggVorbis, WAV (PCM, LPCM), WMA, WMA PRO, WMA VBR*
  3. Support CUE indexing file for APE, FLAC audio format.
*DRM-protected content is not supported.
iSCSI (IP SAN)
  1. iSCSI target with multi-LUNs per target (Up to 256 targets/LUNs combined)
  2. Supports LUN mapping & masking
  3. Online LUN capacity expansion
  4. Support for SPC-3 persistent reservation
  5. Supports MPIO & MC/S
  6. iSCSI LUN backup, one-time snapshot, and restoration
  7. iSCSI connection and management by QNAP Windows Qfinder Pro
  8. Virtual disk drive (via iSCSI initiator)
  9. Max No. of virtual disk drives: 8
Video Station
  1. Supports virtual/smart collections
  2. Tag videos with text, color, and ratings
  3. Share video links to social websites or through email
  4. Sort videos automatically into defined classifications
  5. Display movie posters from IMDB or user upload
  6. Supports displaying subtitles (*.SRT,*.ASS, *.SSA)
  7. Supports Facebook friends login
  8. Supports custom video classification
  9. Supports multi-zone video display
  10. Mobile app: Qvideo for online video browsing and management
Print Server
  1. Max number of printers: 3
  2. Supports Internet Printing Protocol
  3. Print job display and management
  4. IP-based and domain name-based privilege control
App Center
  1. Official and community software add-ons such as Signage Station and Notes Station
Designs and specifications are subject to change without notice.

TS-831X 乙太網路線纜 x 2 電源線
十字螺絲 x 32 (適合 3.5 吋硬碟) 十字螺絲 x 24 (適合 2.5 吋硬碟) 快速安装手册 (QIG)

選購配件

  1. QM2-2P-244A

    QM2-2P-244A

    QM2-2P-344

    QM2-2P-344 (EOL)

    QM2-2P-384

    QM2-2P-384 (EOL)

    QM2-2P2G2T

    QM2-2P2G2T

    QM2-2S-220A

    QM2-2S-220A

    FAN-12CM-T01

    FAN-12CM-T01

    QNA-UC5G1T

    SCR-HDD25A-96

    SCR-HDD25A-96

    SCR-HDD35B-96

    SCR-HDD35B-96

    SP-4BAY-PSU

    SP-4BAY-PSU

    SP-6BAY-PSU

    SP-6BAY-PSU

    SP-TS-TRAY-WOLOCK

    SP-TS-TRAY-WOLOCK

    QXG-10G1T

    QXG-10G1T

    QXG-10G2T-107

    QXG-10G2T-107 (EOL)

    QXG-2G1T-I225

    QXG-2G1T-I225

    QXG-2G2T-I225

    QXG-2G2T-I225

    QXG-2G4T-I225

    QXG-2G4T-I225

    TRX-10GSFP-SR-MLX

    TRX-10GSFP-SR-MLX

    CAB-DAC15M-SFPP

    CAB-DAC15M-SFPP

    CAB-DAC30M-SFPP

    CAB-DAC30M-SFPP

    CAB-DAC50M-SFPP

    CAB-DAC50M-SFPP

    RAM-2GDR3T0-SO-1600

    RAM-2GDR3T0-SO-1600 (EOL)

    RAM-4GDR3-SO-1600

    RAM-4GDR3-SO-1600 (EOL)

    RAM-4GDR3T0-SO-1600

    RAM-4GDR3T0-SO-1600

    RAM-8GDR3-SO-1600

    RAM-8GDR3-SO-1600

原包裝出貨的擴充卡、變壓器及配件自購買日起享有一年保固。

選擇規格

      顯示更多 隱藏更多

      選擇其他偏好的語言：

      open menu
      back to top
