| Operating System | | QNAP Turbo NAS System 3.7 | | | iSCSI (IP SAN) | - iSCSI Target
- Multi-LUNs per Target
- Up to 256 Targets/LUNs Combined
- Supports LUN Mapping & Masking
- Online LUN Capacity Expansion
- Supports SPC-3 Persistent Reservation
- Supports MPIO & MC/S
- iSCSI LUN Backup, One-time Snapshot, and Restore
- iSCSI Connection and Management by QNAP Finder (Windows)
- Virtual Disk Drive (via iSCSI Initiator)
- Stack Chaining Master
- Max No. of Virtual Disk Drives: 8
| |
| Supported Clients | - Apple Mac OS 10.7 or later
- Linux and UNIX
- Microsoft Windows 7, 8, and 10
- Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016
| | | Server Virtualization & Clustering | - Supports VMware vSphere
- Supports Citrix XenServer
- Supports Windows Server 2008 R2 Hyper-V & Failover Clustering
| |
| Supported Browsers | - Microsoft Internet Explorer 10+
- Mozilla Firefox 8+
- Apple Safari 4+
- Google Chrome
| | | Power Management | - Wake on LAN
- Internal Hard Drive Standby Mode
- Scheduled Power on/off (Max 15 Settings)
- Automatic Power on after Power Recovery
- USB and Network UPS Support with SNMP Management
| |
| Multilingual Support | - Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
| | | Access Right Management | - Max No. of Users: 4,096
- Max No. of User Groups: 512
- Max No. of Network Shares: 512
- Batch Users Creation
- Import/Export Users
- User Quota Management
- Subfolder Permissions Support for CIFS/SMB, AFP, FTP and Web File Manager
| |
| File System | - Internal Hard Drive: EXT3, EXT4
- External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
| | | Domain Authentication Integration | - Microsoft Active Directory (AD)
- LDAP Server
- LDAP Client
- Domain Users Login via CIFS/SMB, AFP, FTP, and Web File Manager
| |
| Networking | - TCP/IP (IPv4 & IPv6: Dual Stack)
- Dual Gigabit NICs with Jumbo Frame
- Failover
- Multi-IP Settings
- Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
- Service Binding based on Network Interfaces
- Virtual LAN (VLAN)
- DHCP Client, DHCP Server
- Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
- UPnP & Bonjour Discovery
- USB Wi-Fi Adapter Support
| | | MyCloudNAS Service | - Private Cloud Storage and Sharing
- Free Host Name Registration (DDNS)
- Auto Router Configuration (via UPnP)
- MyCloudNAS Connect for Easy VPN Connection (Windows utility)
| |
| Backup Solution | - Real-time Remote Replication (RTRR)
- Works as Both RTRR Server & Client with Bandwith Control
- Real-time & Scheduled Backup
- Encryption, Compression, File Filter, and Transfer Rate Limitation
- Block-level Remote Replication
- Works as Both Rsync Server & Client with Bandwidth Control
- Encrypted Replication between QNAP NAS Servers
- USB One Touch Backup (Import/Export)
- Desktop Backup by QNAP NetBak Replicator for Windows
- Apple Time Machine Support with Backup Management
- Data Backup to Multiple External Storage Devices
- Data Backup to Cloud Storage (Amazon S3, ElephantDrive)
| | | Storage Plug & Play | - Windows Software: QNAP Finder
- Create and Map Shared Folders
- Create and Connect to iSCSI Target/LUN
| |
| Security | - IP Filter and Policy-based Automatic IP Blocking
- Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
- Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication between QNAP NAS Servers (Rsync over SSH)
- CIFS Host Access Control for Shared Folders
- Antivirus Protection
- FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption*
- AES 256-bit External Drive Encryption*
- Importable SSL Certificate
- Instant Alert via E-mail, SMS, and Beep
| | | Web Administration | - AJAX-based User Interface
- Smart Fan Control
- Dynamic DNS (DDNS)
- SNMP (v2 & v3)
- Resource Monitor
- Network Recycle Bin for File Deletion via CIFS/SMB and AFP
- Automatic Cleanup
- File Type Filter
- Comprehensive Logs (Events & Connection)
- Syslog Client
- Firmware Live Update
- System Settings Backup and Restore
- Restore to Factory Default
- Mobile App Qmanager for Remote Monitoring
| |
| Disk Management | - Single Disk, JBOD, RAID 0, 1, 5, 6, 10, 5+hot spare
- Online RAID Capacity Expansion & Online RAID Level Migration
- Bad Block Scan & Hard Drive S.M.A.R.T.
- RAID Recovery
- Bitmap Support
| | |
| Powerful All-in-one server |
| File Server | - File Sharing across Windows, Mac, and Linux/UNIX
- Windows ACL
- Advanced Folder Permission for SMB, AFP, FTP, Web File Manager
- Shared Folder Aggregation (CIFS/SMB)
- Web File Manager
- Supports ISO Mounting
- Direct File Viewing via Google Doc
- Create and Send Download Links for Public File Sharing with Expiration Time and Password Protection
- Mobile App: Qfile for File Browsing and Management
| | | Photo Station | - Supported File Formats:
- Photo: BMP, JPG, JPE, PNG, TGA, GIF, and more.
- Video: API, MP4, and more.
- Image Slideshow with Background Music, Thumbnails, and Different Playback Modes
- Online Photo Editing by Pixlr Editor
- Geotagging Photos with Google Maps
- Slideshow Sharing (from Private Albums) with Password Protection
- Photo Publishing to Social Websites (Facebook, MySpace, Twitter, Plurk, and Blogger)
- Photo Sharing by Email
| |
| FTP Server | - FTP over SSL/TLS (Explicit)
- Max No. of Concurrent Connections: 256
- FXP Supported
- Passive FTP Port Range Control
- FTP Bandwidth & Connection Control
- Unicode Support
| | | Music Station | - Plays or Shares Music Collections with Web Browser
- Automatic Classification via Media Library
- Supported audio format: MP3, FLAC, OGG, WAV, AIF, AIFF, and more.
* DRM encryption format is not supported. - Internet Radio (MP3)
- Up to 8 Music Alarms
| |
| Backup Server | - Remote Replication Server (over Rsync)
- Real-time Remote Replication to another QNAP NAS or FTP Server
- Apple Time Machine Support
- Windows Client Backup Application: QNAP NetBak Replicator
- Third Party Backup Software Support: Acronis True Image, CA BrightStor, ARCserve Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper, etc.
| | | Download Station | - PC-less BT, FTP, HTTP Download (up to 500 Tasks)
- BT Download
- Supports Magnet Links
- Supports TCP/UDP Tracker Protocol
- Scheduled Download
- Configurable Port Range
- Bandwidth Control
- XMail Mail Server
- Xeams Mail Server
- HTTP/ FTP Download
- Configurable Saving Directory
- Bulk Download with Wildcard Settings
- RapidShare Download Support
- QNAP Download Management Software: QGet
- For Both Windows & Mac OS
- Manage the Download Tasks of Multiple QNAP NAS Remotely over LAN or WAN
| |
| Web Server | - HTTP/HTTPS Connections
- Supports WebDAV Connection
- Support Virtual Host (Max: 32)
- Importable SSL Certificate
| | | Antivirus | - Protection against the Latest Known Viruses, Trojans, and Other Threats
- Free Virus Databases Update on Manual or Scheduled Basis
- Multiple Scan Tasks (Max: 64, Concurrent: 5) with Custom Folder Selection and Scheduled
- Scanning
- Email Notification upon Task Completion or Virus Detection
- Quarantines or Deletes Infected Files
| |
| Database Server | - Built-in MySQL Server
- Web-based Management via phpMyAdmin (QPKG)
| |
| Print Server | - Max No. of Printers: 3
- Supports Internet Printing Protocol
- Print Job Display and Management
- IP- and Domain Name-based Privilege Control
- Supports Apple Bonjour Printing
| |
| Syslog Server | - Centralized Log Monitoring and Archiving
- Immediate E-mail Alerts
- Supports Log Filtering
| |
| RADIUS Server | - Centralized Account Management and Authentication for Network Access
- Supports PAP, EAP-TLS/PAP, and EAPTTLS/PAP Authentication
| |
TFTP Server with PXE Booting
VPN Server | - Secure Remote Access: PPTP & OpenVPN VPN services
- Remote Access to Other Resources on Local Network
- Max No. of Clients: 30
| |
| Surveillance Station | - Max. IP Cameras: 16, optional purchase (2 free license included, supported network cameras)
- Mobile app: Vmobile (iOS & Android)
| |
*The data encryption functions may not available in accordance to the legislative restrictions of some countries.
Design and specifications are subject to change without notice. |
