HS-453DX

HS-453DX

HS-453DX-8G
  • HS-453DX-8G
  • HS-453DX-4G

System Specification
CPU
CPU Intel® Celeron® J4115 4-core/4-thread processor, burst up to 2.5 GHz Intel® Celeron® J4115 4-core/4-thread processor, burst up to 2.5 GHz
CPU Architecture
CPU Architecture 64-bit x86 64-bit x86
Graphic Processors
Graphic Processors Intel® HD Graphics 600 Intel® HD Graphics 600
Floating Point Unit
Floating Point Unit
Encryption Engine
Encryption Engine (AES-NI) (AES-NI)
Hardware-accelerated Transcoding
Hardware-accelerated Transcoding
System Memory
System Memory 8 GB SODIMM DDR4 (2 x 4 GB) 4 GB SODIMM DDR4 (2 x 2 GB)
Maximum Memory
Maximum Memory 8 GB (2 x 4 GB) 8 GB (2 x 4 GB)
Memory Slot
Memory Slot 2 x SODIMM DDR4 1 2 x SODIMM DDR4 1
Flash Memory
Flash Memory 4GB (Dual boot OS protection) 4GB (Dual boot OS protection)
Drive Bay
Drive Bay 2 x 3.5-inch SATA 6Gb/s, 3Gb/s 2 2 x 3.5-inch SATA 6Gb/s, 3Gb/s 2
Drive Compatibility
Drive Compatibility 3.5-inch SATA hard disk drives

2.5-inch SATA solid state drives 3.5-inch SATA hard disk drives

2.5-inch SATA solid state drives
Hot-swappable
Hot-swappable (Not supported M.2 SSD) (Not supported M.2 SSD)
M.2 Slot
M.2 Slot 2 x M.2 2280 SATA 6Gb/s slots 2 x M.2 2280 SATA 6Gb/s slots
SSD Cache Acceleration Support
SSD Cache Acceleration Support

Connections
Gigabit Ethernet Port (RJ45)
Gigabit Ethernet Port (RJ45) 1 1
10 Gigabit Ethernet Port
10 Gigabit Ethernet Port 1 x 10GBASE-T (10G/5G/2.5G/1G/100M) 1 x 10GBASE-T (10G/5G/2.5G/1G/100M)
Jumbo Frame
Jumbo Frame
USB 2.0 port
USB 2.0 port 2 2
USB 3.2 Gen 1 port
USB 3.2 Gen 1 port 3 (1 x USB-C, 2 x USB-A) 3 (1 x USB-C, 2 x USB-A)
IR Sensor
IR Sensor (RM-IR004) (RM-IR004)
HDMI™ Output
HDMI™ Output 2, HDMI™ 2.0 (up to resolution 3840 x 2160 @ 60Hz) + HDMI™ 1.4b (up to 3840 x 2160 @ 30Hz) 2, HDMI™ 2.0 (up to resolution 3840 x 2160 @ 60Hz) + HDMI™ 1.4b (up to 3840 x 2160 @ 30Hz)
Audio Input
Audio Input - (No longer available on units manufactured on or after 2021/1/1) - (No longer available on units manufactured on or after 2021/1/1)
Audio Output
Audio Output - (The line out jack and speaker are no longer available on units manufactured on or after 2021/1/1) - (The line out jack and speaker are no longer available on units manufactured on or after 2021/1/1)

Appearance
Form Factor
Form Factor Set-top design Set-top design
LED Indicators
LED Indicators Power/Status, HDD1-2 Power/Status, HDD1-2
Buttons
Buttons Power, Reset Power, Reset
Dimensions (HxWxD)
Dimensions (HxWxD) 41 × 404 × 220 mm 41 × 404 × 220 mm
Weight (Net)
Weight (Net) 3.89 kg 3.89 kg
Weight (Gross)
Weight (Gross) 3.89 kg 3.89 kg

Others
Operating Temperature
Operating Temperature 0 - 35 °C (32°F - 95°F) 0 - 35 °C (32°F - 95°F)
Storage Temperature
Storage Temperature -20 - 70°C (-4°F - 158°F) -20 - 70°C (-4°F - 158°F)
Relative Humidity
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit
Power Supply Unit External Power Adapter, 90W, 100-240V External Power Adapter, 90W, 100-240V
Power Consumption: Disk Standby Mode
Power Consumption: Disk Standby Mode 13.55 W 13.55 W
Power Consumption: Operating Mode, Typical
Power Consumption: Operating Mode, Typical 22.38 W 3 22.38 W 3
System Warning
System Warning Buzzer Buzzer
Standard Warranty
Standard Warranty 2 2

Networking
Port Trunking / Link Aggregation
Port Trunking / Link Aggregation
Network Service Discovery (UPnP & Bonjour)
Network Service Discovery (UPnP & Bonjour)
Virtual LAN (VLAN)
Virtual LAN (VLAN)
Service Binding Based on Network Interfaces
Service Binding Based on Network Interfaces

Encryption
AES 256-bit Volume-based Encryption
AES 256-bit Volume-based Encryption
AES 256-bit Folder Encryption
AES 256-bit Folder Encryption
External Drive Encryption
External Drive Encryption
Hardware Encryption Engine (Not available in certain countries)
Hardware Encryption Engine (Not available in certain countries)

Snapshot Protection
Snapshot
Snapshot (max 1024) (max 1024)

Storage Management
RAID Recovery
RAID Recovery
Online RAID Capacity Expansion
Online RAID Capacity Expansion
Online RAID Level Migration
Online RAID Level Migration
RAID 10
RAID 10
RAID 6
RAID 6
RAID 5+ Spare
RAID 5+ Spare
RAID 5
RAID 5
RAID 1
RAID 1
RAID 0
RAID 0
JBOD
JBOD
Single Disk
Single Disk
Global Hot Spare
Global Hot Spare
Storage Pool
Storage Pool
SSD Caching
SSD Caching
iSCSI Target
iSCSI Target
iSCSI LUN Snapshot/Backup
iSCSI LUN Snapshot/Backup
Thin-provisioned volume
Thin-provisioned volume
SSD Over-provisioning
SSD Over-provisioning

Virtualization
Container Station
Container Station
Virtualization Station
Virtualization Station
Linux Station (RAM of NAS >= 4GB)
Linux Station (RAM of NAS >= 4GB)
VMware Ready®
VMware Ready®
Citrix Ready
Citrix Ready
Microsoft Hyper-V Compatibility
Microsoft Hyper-V Compatibility

Privilege
Domain Controller
Domain Controller

Software Application
Wake on LAN (WOL)
Wake on LAN (WOL)

Sharing Capacity
Max. Number of Users
Max. Number of Users 4096 4096
Max. Number of User Groups
Max. Number of User Groups 512 512
Max. Number of Share Folders
Max. Number of Share Folders 512 512
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 1500 1500

Supported Languages
Language
Language English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek
