TS-262

Intel Dual-Core 2.5GbE Multimedia NAS with M.2 PCIe slots and PCIe expandability

Upgrade your home network to 2.5GbE

Wi-Fi 6 and 5G are becoming the new normal for networking, and there’s no reason why your home wired network shouldn’t also get a boost. The TS-262 comes with single 2.5GbE RJ45 LAN port which supports existing CAT5e cables. If your computers don’t have 2.5GbE ports, you can use QNAP’s USB 3.2 Gen 1 to 5GbE adapter (model name QNA-UC5G1T) to take advantage of the huge speed increase that 2.5GbE provides over standard Gigabit Ethernet. QNAP also provide affordable 2.5GbE switches and other adapters for you to take full advantage of the TS-262’s 2.5GbE connectivity.

Learn More: QNAP’s 2.5GbE solutions

Intel dual-core processor burst up to 2.9 GHz

The TS-262 is powered by an Intel® Celeron® N4505 dual-core processor (burst up to 2.9 GHz), and supports SATA 6 Gb/s drives. The Intel® AES-NI encryption engine boosts encryption performance while also maintaining the security of your NAS data. You can flexibly install NVMe SSDs in the M.2 PCIe slots for cache acceleration to maximize network and storage performance for data-intensive applications or enable Qtier for auto-tiered storage for higher storage efficiency.

Windows File Transfer (1 x 2.5GbE, 10GB file)

Upload

295 MB/s

Download

295 MB/s

Windows File Transfer (1 x 10GbE, 10GB File)

Upload

751 MB/s

Download

1181 MB/s

Windows Sequential File Transfer (2 x 10GbE, 1MB)

Write

1505 MB/s

Read

1644 MB/s

Tested in QNAP Labs. Figures may vary by environment.

Test environment:
NAS: TS-262-4G
OS: QTS 5.0.0
Volume type:
2 x Samsung 960 PRO 1 TB M.2 SSD, RAID 1, thick volume
Client PC:
Windows Server 2016 Standard, Intel i7-6700 3.4Ghz, 64GB RAM
IOmeter:
RAM*4, 30-sec ramp up time, 3-min seq. run time, 1 workers, 32-outstanding

Virtualization Certifications Supported by TS-262

Check QNAP NAS with Support for Virtualization application

Accelerate AI–powered image recognition and caching with TPU and PCIe expansion

The TS-262 has two M.2 PCIe Gen3 slots, enabling SSD caching or SSD storage pools for improved performance, or Edge TPU for AI image recognition.

How to Install

2 x M.2 2280 PCIe Gen 3 x1 slots

• Install M.2 NVMe SSDs for cache acceleration or efficient tiered storage

  The TS-262 supports SSD caching and features two M.2 slots that support M.2 PCIe NVMe SSDs with 2280 form factors (sold separately) for boosting overall NAS performance. Qtier™ technology can also be used to empower the TS-262 with auto tiering that helps continuously optimize storage efficiency across all installed storage devices.

  Learn More: SSD cache, Qtier

• Accelerate AI–powered image recognition with TPU

  By leveraging a Google Edge TPU to QNAP AI Core (the AI-powered engine for image recognition), the TS-262 can perform high-speed face and object recognition. Google Edge TPU enables QuMagie to quickly process thousands of photos with high-speed AI Image recognition and classification, and QVR Face to analyze real-time video for instant facial recognition.

  Note: Purchase this item from Coral website

  Learn More: Edge TPU Accelerator

SSD caching and auto-tiering enable 24/7 optimized storage efficiency

While SSD prices continue to fall, and SSD capacity and performance continue to increase, organizations can easily take advantage of SSD strengths. The TS-262 supports numerous SSD-aware features that significantly maximize NAS performance with high cost-effectiveness.

Learn More: QNAP’s SSD technology

SSD over-provisioning (Over-provisioning)	SSD cache acceleration	Qtier for auto-tiering
You can add additional SSD over-provisioning (1% ~60%) to avoid write amplification and improve SSD random write speeds and endurance. You can potentially attain enterprise-grade SSD performance levels from affordable consumer SSDs!	Enables SSD caching for increasing IOPS performance and reducing latency for storage volume. This feature is perfect for IOPS-demanding applications including databases and virtualization. The TS-262 also supports write-only cache to boost write-intensive applications.	Qtier technology drives auto-tiered storage with continuous data optimization across high-performance SSDs and high-capacity HDDs based on access frequency. I/O-Aware Qtier can reserve a cache-like space in the SSD tiered to handle burst I/O in real time.

Direct 4K HDMI™ output for multimedia

The TS-262 supports hardware decoding and real-time transcoding*. The HDMI™ 2.1 output supports up to 4K (3840 x 2160p) @60Hz, allowing you to directly enjoy high-res videos on a TV or monitor.

The TS-262’s hardware provides H.264 hardware decoding, encoding and transcoding capabilities. However, playback quality may vary due to factors including playback software, file formats, system usage, and available bandwidth. H.265 hardware transcoding requires installing CAYIN MediaSign Player with Plus license.

Faster image identification with integrated Intel® OpenVINO™ AI engine.

With integrated Intel® OpenVINO™ AI computing resources, the TS-262 accelerates AI image recognition performance without impacting other applications or services. QNAP AI Core primarily works with the QuMagie application.

•

  QuMagie photo management

  Easy-to-use photo management solution that integrates AI image recognition and intelligent classification for your collection.

  With GPU acceleration

  % Performance boost

Tested in QNAP Labs. Figures may vary by environment and NAS models.
Test environment: NAS: TS-462

Abundant I/O capabilities with PCIe expansion

The TS-262 has a PCIe Gen3 x2 slot that allows for installing a expansion card to expand the TS-262‘s potential.

2.5/5/10GbE network card

Enable lightning-fast throughput for bandwidth-demanding tasks (such as massive data transmission or fast backup/restore).

Learn More: QNAP network expansion cards

Wireless adapter

Install a QXP-W6-AX200 Wi-Fi 6 wireless adapter to turn the TS-262 into a wireless NAS. Or make the TS-262 a wireless access point by installing the QWA-AC2600 wireless adapter and the WirelessAP Station app.

Learn More: Wireless network expansion card

QTS 5. Fast, smooth, and easy-to-use!

The TS-262 supports the cutting-edge QTS 5, which builds upon its solid foundations with a smoother user interface and much more!

Learn More: QTS 5

• Brighter. Smoother. You’ll like it.

  When navigating QTS 5, you will notice a finer attention to detail for a superior browsing experience. Enjoy a smoother NAS experience, comfortable visual design, and find your favorite apps quicker.

• Get started with the notice board

  When performing first-time installation, the notice board guides you through the setup process. Simply follow the step-by-step instructions for a quick and easy setup.

• Smooth and reactive user interface

  Whether clicking buttons, switching between apps, expanding/collapsing windows – every action is much smoother. The search bar in the main menu also assists in quickly finding desired apps.

The best storage for your high-resolution multimedia files

High-resolution RAW files eat up phone storage so quickly. Whether you are a photographer enthusiastic, YouTuber, or professional photo/video editors, use the TS-262 with high-capacity hard drives to alleviate your storage anxiety and organize files efficiently as the best storage center.

•

  RAID protection

  RAID redundancy protects data against hard drive failure. By dedicating some drives to redundancy, if a drive fails you can simply replace it with a new drive and avoid data loss.

  Learn More: RAID management

•

  Storage for massive photos

  The AI-powered QuMagie with intelligent face and object recognition brings you the ultimate photo management and sharing solution. Includes timeline scrolling, customizable folder covers, iOS® Live Photo display, a powerful search tool, and more.

  Learn More: AI-powered QuMagie, QuMagie Mobile App

•

  Storage for music collections

  Use Music Station to collect and play lossless music, sing along with lyrics, and share albums, playlists or folders with friends and family. You can also put tons of music right in your pocket using the Qmusic mobile app.

  Learn More: Music Station, Qmusic mobile app App

•

  Store high-resolution videos

  Centrally collect GoPro diaries, videos of your family, friends, and pets in Video Station, and easily share your favorites. Take all your videos with you on your mobile devices using the Qvideo mobile app.

  Learn More: Video Station, Qvideo mobile App

Stream all your media to every device in the house

The TS-262 is a complete multimedia center, allowing fast and easy streaming for photos, music and video to TVs, computers and mobile devices.

•

  Plex multimedia streaming

  By installing Plex® Media Server from the App Center, you can stream media files stored on the TS-262 to mobiles and media streaming devices (including DLNA®, Roku®, Amazon Fire TV® and Google Chromecast™).

  Learn More



•

  Stream to Android TV™ or Apple TV®

  Qmedia is QNAP’s exclusive streaming app, allowing streaming audio, photos, and videos from the TS-262 to Android TV™, Apple TV® (via Qmedia) or set-top boxes.

  Learn More



	Apple TV	Amazon Fire TV	Roku
DLNA
PLEX
Qmedia

Connect to a TV or Monitor with HDMI™

With HDMI™ output, the TS-262 allows you to directly enjoy multimedia content, use web browsers, manage your NAS, or watch recorded surveillance footage or live feeds on your NAS.

•

  HybridDesk Station

  Your TS-262 not only provides storage for your multimedia, but it can also be used as a Home Theater PC! Connect the TS-262 to an TV or A/V Receiver with HDMI™ , install HybridDesk Station, and easily watch movies or play music using the QNAP remote control (sold separately) or the Qremote mobile app.

  Learn More

•

  Use your NAS as a PC

  Simply connect a keyboard, mouse, and HDMI™ display to the TS-262 to use it as a PC - directly accessing your NAS files and services, and browsing the Internet with Google Chrome™ and Firefox® are just that easy.

•

  Monitor surveillance videos

  Use the QVR Pro Client on HybridDesk Station to monitor live views and play recorded footage. You can also switch between different channels to view from different angles for greater coverage.

•

  Ultimate visual experience with 4K HDMI™ output

  The TS-262 has an HDMI™ 2.0 port which supports 4K (3840 x 2160) 60Hz output.

An easy-to-use, all-in-one backup solution

The TS-262 can do many things, but at its heart is a complete backup solution to protect your files and data. By regularly backing up your files and device content, you can make data loss a thing of the past.

•

  Back up Windows®/Mac® files

  For Windows®, install NetBak Replicator to back up your PC files to the TS-262, or use NetBak PC Agent for full system backup. In macOS®, simply set up the built-in Time Machine® to back up files to NAS.

  Learn More: NetBak Replicator utility, NetBak PC Agent utility

•

  Back up photos on mobile devices

  Install Qfile or QuMagie mobile app and enable the “auto-upload” function. Photos will be automatically uploaded to your TS-262 as soon as they are taken.

  Learn More: QuMagie Mobile app, Qfile mobile app

•

  Back up Google Drive™

  Hybrid Backup Sync can safely back up files and data from Google Drive™ to the TS-262, helping you save money on cloud storage costs.

•

  Back up NAS files to the cloud

  Hybrid Backup Sync supports QNAP-hosted myQNAPcloud Storage and numerous public cloud services, allowing you to effortlessly back up or sync NAS files to cloud storage.

  Learn More: Hybrid Backup Sync multi-cloud backup, QNAP-hosted myQNAPcloud Storage

•

  Back up WordPress sites

  Enjoy efficient WordPress backup/restore and site migration by leveraging the user-friendly Multi-Application Recovery Service (MARS), and easily batch backup WordPress files and database to the TS-262 with backup scheduling.

  Learn More: WordPress backup solution

Protect your data from ransomware threats with Snapshots

Snapshots are an advanced backup method and are normally reserved for high-end business NAS. QNAP provides snapshots as standard for all NAS – including the TS-262. Snapshots work by recording the current state of the system, allowing it to be restored back this state at any time - greatly helping in mitigating the threat of ransomware.

Read the guide for home data protection against ransomware

1. 1. Back up PCs to your NAS

   Always remember to back up! You should routinely (or automatically) back up files and data from your computer to your TS-262.



2. 2. Take snapshots within seconds

   Instantly take snapshots to record the current state of your system and data. You can quickly restore files and data to a previously recorded state by selecting a snapshot version from a specific time point.



3. 3. Back up snapshots

   Multiply data protection by backing up snapshot files! Replicate snapshots in the TS-262 to a remote NAS (Snapshot Replica) and only copy the changes made. This helps save time & bandwidth, and can be run manually or on a scheduled basis.



4. 4. Restore data using snapshots

   Snapshot content can be quickly restored to a local NAS, or restored on a folder/file basis to a local/remote NAS or cloud storage. You can also conveniently view and restore snapshots from the client side.



• 1
• 2
• 3
• 4

Back up PCs to your NAS

Always remember to back up! You should routinely (or automatically) back up files and data from your computer to your TS-262.

Take snapshots within seconds

Instantly take snapshots to record the current state of your system and data. You can quickly restore files and data to a previously recorded state by selecting a snapshot version from a specific time point.

Back up snapshots

Multiply data protection by backing up snapshot files! Replicate snapshots in the TS-262 to a remote NAS (Snapshot Replica) and only copy the changes made. This helps save time & bandwidth, and can be run manually or on a scheduled basis.

Restore data using snapshots

Snapshot content can be quickly restored to a local NAS, or restored on a folder/file basis to a local/remote NAS or cloud storage. You can also conveniently view and restore snapshots from the client side.

Tips for a more productive workday

With a wide range of awesome apps, you can easily access files from various devices, instantly synchronize files with friends’ or colleague’s devices, quickly find specific files, and automatically organize your documents and media files. You can also map the TS-262’s shared folders as network drives on your computers, making accessing NAS files easy and intuitive. The TS-262 helps you save time while being more efficient and productive.

• File Station

  Easily manage files stored in your TS-262 using the web-based File Station. The Qfile companion mobile app also puts all your files at your fingertips, providing a complete personal cloud service that is accessible from anywhere!

  Learn More: File Station

• Qsync

  Qsync is a perfect replacement of Dropbox®, allowing you to synchronize files with computers and mobile devices belonging to your family, friends, colleagues, and clients.

  Learn More: Qsync

• Qsirch

  QNAP’s powerful, Google™-like search tool helps you quickly find images, music, videos, documents, and emails by keywords, color, and more search conditions.

  Learn More: Qsirch

• Qfiling

  Save time organizing and archiving your files with Qfiling. Simply categorize your files, set a schedule, and Qfiling will automatically organize and archive them.

  Learn More: Qfiling

Access your NAS from anywhere

The myQNAPcloud service enables quick and easy remote access to your TS-262, allowing you to be always connected without needing to configure complex network settings. With myQNAPcloud Link you are provided with a unique domain name for your TS-262, and will automatically connect using the best method based on your network environment.

Learn More: myQNAPcloud service

Easily build a wallet-friendly home surveillance system!

With the subscription-based QVR Elite smart surveillance solution you only pay for the channel licenses you need, allowing you to affordably safeguard your property. You can arrange a dedicated, independent storage space for surveillance data on the TS-262 and enjoy simplified camera management, storage space allocation, camera live viewing and playback. Recordings are saved as MP4 files for playback on nearly every device. You can also use USB webcams as network cameras with the QUSBCam2 app, and remotely monitor your surveillance feeds at any time with the QVR Pro Client companion mobile app.

QVR Elite smart surveillance systemQVR Pro Client mobile app

• Free embedded channels

  2 IP camera channels

• Subscription-based

  Monthly US $1.99 /channel

• Mobile app

  QVR Pro Client and mobile app

• Video format

  MP4

• Total camera channels

  Scalable with optional licenses

• Scalable storage

  NAS expansion units

Flexible and economical storage expansion

QNAP provides easy and affordable solutions to expand your NAS storage capacity.

•

  Attach QNAP expansion enclosures

  Connect expansion enclosures to the TS-262, and manage NAS storage expansion with the user-friendly Storage & Snapshots Manager app.

  Learn More

•

  Mount cloud storage or remote file servers

  Mount cloud storage or remote file servers to expand the capacity of the TS-262 while also centrally managing files on the NAS, cloud storage, and remote devices.

  Learn More

•

  Migrate to a new NAS

  Install your NAS hard drives into a larger QNAP NAS and retain all your existing data and configurations.

  Learn More

•

  Upgrade RAID capacity

  Hot-swap lower-capacity drives with larger-capacity drives to expand your NAS capacity so it can grow with your files and multimedia collections.

  Learn More

Extend hardware warranty up to 5 years

The TS-262 is backed by a 2-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.

Learn More
