TS-470 Pro
4-bay home & SOHO NAS for personal cloud and multimedia experience
Home > Product overview > Home & SOHO > TS-x70 Pro Series > TS-470 Pro
Features Specification Utilities Popular downloads
CPU Intel® Core™ i3-3220 3.3 GHz Dual-core Processor
DRAM

TS-470 Pro-16G: 16GB SO-DIMM RAM
TS-470 Pro: 2GB SO-DIMM RAM

Flash Memory 512MB DOM
Hard Disk Drive 4 x 3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
NOTE:
1. The system is shipped without HDD.
2.For the HDD compatibility list, please visit www.qnap.com/compatibility
LAN Port 2 x Gigabit RJ-45 Ethernet ports (expandable to 4 x GbE ports or 2 x GbE + 2 x 10GbE ports)
LED Indicators Status, USB, LAN, HDD 1 - 4
USB 2 x USB 3.0 port (rear)
3 x USB 2.0 port (front: 1, rear:2)
Support USB printer, pen drive, USB hub (front), and USB UPS etc.
Hard Disk Tray 4 x Hot-swappable tray with key lock
eSATA 2 x eSATA port (rear)
HDMI HDMI x 1
Audio Out 1(reserved)
Audio In 1(reserved)
Buttons Power, Reset, USB One Touch Backup
Alarm Buzzer System warning
LCD Panel Monochrome LCD display with backlight, Enter and Select buttons for configuration
Form Factor Tower
Secure Design K-lock security slot for theft prevention
Fan 1 x quiet cooling fan (9 cm, 12V DC)
PCI-E Slot 1 (for optional network or storage capacity expansion)
Dimensions 177 (H) x 180 (W) x 235 (D) mm
6.97 (H) x7.09 (W) x 9.25 (D) inch
Weight Net weight: 4.56 kg (10.05 lbs)
Gross weight: 5.7 kg (12.57 lbs)
Power Consumption (W) Sleep mode: 22.8W
In Operation: 38.2W
Power-off (in WOL mode): 1W
(with 4 x 2TB HDD installed)
Temperature 0-40˚C
Humidity 5~95% RH non-condensing, wet bulb: 27˚C
Power Supply Input: 100-240V AC, 50/60Hz
Output: 250W
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.

* Sound Level Test Environment:
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
