TS-h3087XU-RP, TS-h2287XU-RP, TS-h1887XU-RP, TS-h987XU-RP Compare products

	TS-h3087XU-RP TS-h3087XU-RP-E2378-64G TS-h3087XU-RP-E2378-64G	TS-h2287XU-RP TS-h2287XU-RP-E2336-32G TS-h2287XU-RP-E2336-32G TS-h2287XU-RP-E2378-64G	TS-h1887XU-RP TS-h1887XU-RP-E2334-16G TS-h1887XU-RP-E2334-16G TS-h1887XU-RP-E2336-32G	TS-h987XU-RP TS-h987XU-RP-E2334-16G TS-h987XU-RP-E2334-16G

System Specification


CPU
CPU	Intel® Xeon® E-2378 8C 16T 2.6GHz, up to 4.8GHz	Intel® Xeon® E-2336 6C 12T 2.9GHz, up to 4.8GHz Intel® Xeon® E-2378 8C 16T 2.6GHz, up to 4.8GHz	Intel® Xeon® E-2334 4C 8T 3.4GHz, up to 4.8GHz Intel® Xeon® E-2336 6C 12T 2.9GHz, up to 4.8GHz	Intel® Xeon® E-2334 4C 8T 3.4GHz, up to 4.8GHz
CPU Architecture
CPU Architecture	64-bit x86	64-bit x86 64-bit x86	64-bit x86 64-bit x86	64-bit x86
Graphic Processors
Graphic Processors	Optional via a PCIe adapter	Optional via a PCIe adapter Optional via a PCIe adapter	Optional via a PCIe adapter Optional via a PCIe adapter
Floating Point Unit
Floating Point Unit
Encryption Engine
Encryption Engine	(AES-NI)	(AES-NI) (AES-NI)	(AES-NI) (AES-NI)	(AES-NI)
System Memory
System Memory	64 GB ECC DDR4 (2 x 32 GB)	32 GB ECC DDR4 (1 x 32 GB) 64 GB ECC DDR4 (2 x 32 GB)	16 GB ECC DDR4 (1 x 16 GB) 32 GB ECC DDR4 (1 x 32 GB)	16 GB ECC DDR4 (1 x 16 GB)
Maximum Memory
Maximum Memory	128GB (4 x 32 GB)	128GB (4 x 32 GB) 128GB (4 x 32 GB)	128GB (4 x 32 GB) 128GB (4 x 32 GB)	128GB (4 x 32 GB)
Memory Slot
Memory Slot	4 x ECC UDIMM DDR4 ¹	4 x ECC UDIMM DDR4 ¹ 4 x ECC UDIMM DDR4 ¹	4 x ECC UDIMM DDR4 ¹ 4 x ECC UDIMM DDR4 ¹	4 x ECC UDIMM DDR4 ¹
Flash Memory
Flash Memory	5GB (Dual boot OS protection)	5GB (Dual boot OS protection) 5GB (Dual boot OS protection)	5GB (Dual boot OS protection) 5GB (Dual boot OS protection)	5GB (Dual boot OS protection)
Drive Bay
Drive Bay	30 (24 x 3.5-inch SATA + 6 x 2.5-inch SATA)	22 (16 x 3.5-inch SATA + 6 x 2.5-inch SATA) 22 (16 x 3.5-inch SATA + 6 x 2.5-inch SATA)	18 (12 x 3.5-inch SATA + 6 x 2.5-inch SATA) 18 (12 x 3.5-inch SATA + 6 x 2.5-inch SATA)	9 (4 x 3.5-inch SATA + 5 x 2.5-inch U.2 PCIe / SATA) ²
Drive Compatibility
Drive Compatibility	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch SATA solid state drives	3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch U.2/U.3 NVMe PCIe solid state drives 2.5-inch SATA solid state drives The 2.5-inch bay only support maximum 7mm height drives.
Hot-swappable
Hot-swappable	(Not supported M.2 SSD)	(Not supported M.2 SSD) (Not supported M.2 SSD)	(Not supported M.2 SSD) (Not supported M.2 SSD)	(Not supported M.2 SSD)
M.2 Slot
M.2 Slot	Optional via a QM2 PCIe adapter	Optional via a QM2 PCIe adapter Optional via a QM2 PCIe adapter	Optional via a QM2 PCIe adapter Optional via a QM2 PCIe adapter	Optional via a QM2 PCIe adapter
SSD Cache Acceleration Support
SSD Cache Acceleration Support

Connections


GPU pass-through
GPU pass-through
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2.5 Gigabit Ethernet Port (2.5G/1G/100M)	2 (2.5G/1G/100M)	2 (2.5G/1G/100M) 2 (2.5G/1G/100M)	2 (2.5G/1G/100M) 2 (2.5G/1G/100M)	2 (2.5G/1G/100M)
10 Gigabit Ethernet Port
10 Gigabit Ethernet Port	2 x 10GBASE-T (10G/5G/2.5G/1G/100M)	2 x 10GBASE-T (10G/5G/2.5G/1G/100M) 2 x 10GBASE-T (10G/5G/2.5G/1G/100M)	2 x 10GBASE-T (10G/5G/2.5G/1G/100M) 2 x 10GBASE-T (10G/5G/2.5G/1G/100M)	2 x 10GBASE-T (10G/5G/2.5G/1G/100M)
25 Gigabit Ethernet Port
25 Gigabit Ethernet Port	Optional via a PCIe adapter	Optional via a PCIe adapter Optional via a PCIe adapter	Optional via a PCIe adapter Optional via a PCIe adapter	Optional via a PCIe adapter
PCIe Slot
PCIe Slot	3 (2 x Gen4 x4 +1 x Gen 4 x8) ³	3 (2 x Gen4 x4 +1 x Gen 4 x8) ⁴ 3 (2 x Gen4 x4 +1 x Gen 4 x8) ⁴	3 (2 x Gen4 x4 +1 x Gen 4 x8) ⁵ 3 (2 x Gen4 x4 +1 x Gen 4 x8) ⁵	1 x Gen4 x8 ⁶
USB 3.2 Gen 2 (10Gbps) Port
USB 3.2 Gen 2 (10Gbps) Port	4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps	4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps 4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps	4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps 4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps	4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
HDMI™ Output
HDMI™ Output	Optional via a PCIe adapter	Optional via a PCIe adapter Optional via a PCIe adapter	Optional via a PCIe adapter Optional via a PCIe adapter

Appearance


Form Factor
Form Factor	4U Rackmount	3U Rackmount 3U Rackmount	2U Rackmount 2U Rackmount	1U Rackmount
LED Indicators
LED Indicators	Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red)	Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red) Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red)	Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red) Status (Green/Red) LAN (Green) USB (Blue) HDD status (Green/Red)	Status (Green/Red) LAN (Green) HDD status (Green/Red)
Buttons
Buttons	Power, Reset	Power, Reset Power, Reset	Power, Reset Power, Reset	Power, Reset
Dimensions (HxWxD)
Dimensions (HxWxD)	6.94 × 17.39 × 24.81 inch	5.17 × 17.01 × 20.14 inch 5.17 × 17.01 × 20.14 inch	3.49 × 17.01 × 20.13 inch 3.49 × 17.01 × 20.13 inch	1.7 × 16.93 × 18.86 inch
Weight (Net)
Weight (Net)	52.45 lbs	38.51 lbs 38.51 lbs	32.78 lbs 32.78 lbs	20.94 lbs
Weight (Gross)
Weight (Gross)	64.22 lbs	48.15 lbs 48.15 lbs	41.89 lbs 41.89 lbs	25.35 lbs

Others


Operating Temperature
Operating Temperature	0 - 40 °C (32°F - 104°F)	0 - 40 °C (32°F - 104°F) 0 - 40 °C (32°F - 104°F)	0 - 40 °C (32°F - 104°F) 0 - 40 °C (32°F - 104°F)	0 - 40 °C (32°F - 104°F)
Storage Temperature
Storage Temperature	-20 - 70°C (-4°F - 158°F)	-20 - 70°C (-4°F - 158°F) -20 - 70°C (-4°F - 158°F)	-20 - 70°C (-4°F - 158°F) -20 - 70°C (-4°F - 158°F)	-20 - 70°C (-4°F - 158°F)
Relative Humidity
Relative Humidity	5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)	5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F) 5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)	5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F) 5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)	5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit
Power Supply Unit	800W (x2) PSU	550W (x2) PSU 550W (x2) PSU	550W (x2) PSU 550W (x2) PSU	300W (x2) PSU
Power Consumption: Disk Standby Mode
Power Consumption: Disk Standby Mode	149.92 W	165.39 W 165.39 W	118.77 W 118.77 W	114.6 W
Power Consumption: Operating Mode, Typical
Power Consumption: Operating Mode, Typical	219.03 W	228 W 228 W	148.94 W 148.94 W	120.58 W
Fan
Fan	4 x 80mm, 12VDC	3 x 60mm + 1 x 80mm, 12VDC 3 x 60mm + 1 x 80mm, 12VDC	4 x 60mm, 12VDC 4 x 60mm, 12VDC	4 x 40mm, 12VDC
Standard Warranty
Standard Warranty	5	5 5	5 5	5

Networking


Port Trunking / Link Aggregation
Port Trunking / Link Aggregation
Network Service Discovery (UPnP & Bonjour)
Network Service Discovery (UPnP & Bonjour)
Virtual LAN (VLAN)
Virtual LAN (VLAN)
Service Binding Based on Network Interfaces
Service Binding Based on Network Interfaces

Encryption


AES 256-bit Volume-based Encryption
AES 256-bit Volume-based Encryption
AES 256-bit Folder Encryption
AES 256-bit Folder Encryption
External Drive Encryption
External Drive Encryption
Hardware Encryption Engine (Not available in certain countries)
Hardware Encryption Engine (Not available in certain countries)

Snapshot Protection


Snapshot
Snapshot

Storage Management


RAID Recovery
RAID Recovery
Online RAID Capacity Expansion
Online RAID Capacity Expansion
Online RAID Level Migration
Online RAID Level Migration	QTS: QuTS hero: N/A	QTS: QuTS hero: N/A QTS: QuTS hero: N/A	QTS: QuTS hero: N/A QTS: QuTS hero: N/A	QTS: QuTS hero: N/A
RAID 50/60
RAID 50/60
RAID 10+ hot spare
RAID 10+ hot spare
RAID 10
RAID 10
RAID 6+ hot spare
RAID 6+ hot spare
RAID 6
RAID 6
RAID 5+ Spare
RAID 5+ Spare
RAID 5
RAID 5
RAID 1
RAID 1
RAID 0
RAID 0
RAID TP
RAID TP	QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero:
Triple Mirror
Triple Mirror	QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero:
JBOD
JBOD
Single Disk
Single Disk
Global Hot Spare
Global Hot Spare
Storage Pool
Storage Pool
SSD Caching
SSD Caching
iSCSI Target
iSCSI Target
iSCSI LUN Snapshot/Backup
iSCSI LUN Snapshot/Backup
Thin-provisioned volume
Thin-provisioned volume
Deduplication
Deduplication	QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero:
Compression
Compression	QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero:
Write Coalescing
Write Coalescing	QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero:
SSD Over-provisioning
SSD Over-provisioning	QTS: QuTS hero: N/A	QTS: QuTS hero: N/A QTS: QuTS hero: N/A	QTS: QuTS hero: N/A QTS: QuTS hero: N/A	QTS: QuTS hero: N/A
Pool Over-provisioning
Pool Over-provisioning	QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero: QTS: N/A QuTS hero:	QTS: N/A QuTS hero:

Virtualization


Container Station
Container Station
Virtualization Station
Virtualization Station
Linux Station (RAM of NAS >= 4GB)
Linux Station (RAM of NAS >= 4GB)
VMware Ready®
VMware Ready®
Citrix Ready
Citrix Ready
Microsoft Hyper-V Compatibility
Microsoft Hyper-V Compatibility

Privilege


Domain Controller
Domain Controller

Software Application


Wake on LAN (WOL)
Wake on LAN (WOL)

Sharing Capacity


Max. Number of Users
Max. Number of Users	4096	4096 4096	4096 4096	4096
Max. Number of User Groups
Max. Number of User Groups	512	512 512	512 512	512
Max. Number of Share Folders
Max. Number of Share Folders	256	256 256	256 256	256
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
Max. Number of Concurrent Connections (CIFS) - with Max. Memory	11000	11000 11000	11000 11000	11000

Supported Languages


Language
Language	English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek	English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek	English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek	English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek
